Features:
Designed to support up to 150 pounds of weight
Mounts to the side of the drawer
Provides easy access to the drawer with full extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Detent: Also known as anti-rebound, slide detent acts like a brake; ensuring your drawers do not roll back open when closed with too much force.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 22-1/2″
Slide Length: 22″
Extension Type: Full Extension
Slide Type: Ball Bearing
Weight Capacity: 150 lbs
Material: Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Mounting hardware not included
Product Variations:
8500B 18: 18 Inch Drawer Slide
8500B 20: 20 Inch Drawer Slide
8500B 22 (This Model): 22 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt 8500 Collection
Specifications
| Height | 3.79 in. |
| Width | 0.5 in. |
| Length | 22 in. |
| Extension | 22 in. |
| Nominal Length | 22 in. |
| Quantity | 2 |
| Width mm | 13 mm |
| Max Capacity (Pounds) | 150 lbs. |
| Minimum Clearance | 0.5 in. |
| Drainboard Length | 22.5 in. |
| Height mm | 96 mm |
| Minimum Cabinet Depth | 22 in. |
| Maximum Drawer Width | 36 in. |
| Material | Steel |
| Insulation Type | Side Mount |
| Mounting Type | Side Mount |
| Adjustable | No |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Push to Open | No |
| Self Closing | No |
| Soft Close | No |
| Extension Type | Full Extension |
| Detent | Yes |
| Disconnect Style | Lever |
| Slide Type | Ball Bearing |
| Collection | 8500 |
| Manufacturer Warranty | Limited Lifetime |
| Approved for Commercial Use | Yes, No |
| Series | 8500 |
| BHMA Certification | Grade 1 |
| Color | Anochrome |
| Color Tone | Silver Tones |
