Features:
Designed to support up to 140 lbs of weight
Mounts to the side of the drawer for easy installation
Provides easy access to the drawer with over travel slides
Butterfly lever disconnect allows for easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Meets the minimum requirements for BHMA Grade 1 Certification
Includes a limited lifetime manufacturer warranty
Mounting hardware is not included
Requires #7 x 1/2″ Phillips truss head screws for installation
Product Technologies:
Soft Close: Whether large or small, heavy or light, soft closing action keeps drawers from slamming closed. It adapts to various closing speeds and features overload safety to protect the system from damage over time.
Specifications:
Side Length: 17-11/16″
Nominal Length: 18″
Weight Capacity: 140 lbs.
Recommended Drawer Length: 18-1/2″
Maximum Drawer Width: 36″
Minimum Clearance: 1/2″
Quantity: 2
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt 8655FM Collection
Specifications
| Height | 1.98 in. |
| Product Weight | 3.5 lbs. |
| Width | 0.51 in. |
| Length | 17.7 in. |
| Extension | 19 in. |
| Nominal Length | 18 in. |
| Quantity | 2 |
| Max Capacity (Pounds) | 140 lbs. |
| Drainboard Length | 18.5 in. |
| Maximum Drawer Width | 36 in. |
| Minimum Clearance | 0.52 in. |
| Material | Steel |
| Insulation Type | Side Mount |
| Adjustable | No |
| Soft Close | Yes |
| Extension Type | Over Travel |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Push to Open | No |
| Self Closing | Yes |
| Detent | No |
| Disconnect Style | Lever |
| Slide Type | Ball Bearing |
| Approved for Commercial Use | Yes |
| Manufacturer Warranty | Limited Lifetime |
| BHMA Certification | Grade 1 |
| Series | 8655FM |
| Color | Zinc |
| Color Tone | Greys |
