Features:
Designed to support up to 100 pounds of weight
Mounts to the side of the drawer
Provides easy access to the drawer with 3/4 extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Soft Close: Whether large or small, heavy or light, soft closing action keeps drawers from slamming closed. It adapts to various closing speeds and features overload safety to protect the system from damage over time.
3/4 Extension Slides: 3/4 extension slides pull out of the cabinet partway, leaving some of the drawer or pull-out inside the cabinet. Ideal for situations with heavier loads and where rear access is not as important.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 14-1/2″
Slide Length: 14″
Extension: 11-15/16″
Extension Type: 3/4 Extension
Slide Type: Ball Bearing
Weight Capacity: 100 lbs
Material: Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Product Variations:
GS4270 12: 12 Inch Drawer Slide
GS4270 14 (This Model): 14 Inch Drawer Slide
GS4270 16: 16 Inch Drawer Slide
GS4270 18: 18 Inch Drawer Slide
GS4270 20: 20 Inch Drawer Slide
GS4270 22: 22 Inch Drawer Slide
GS4270 24: 24 Inch Drawer Slide
GS4270 26: 26 Inch Drawer Slide
GS4270 28: 28 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt Gslide Collection
Specifications
| Extension | 11.9 in. |
| Height | 1.79 in. |
| Width | 0.5 in. |
| Quantity | 2 |
| Length | 14 in. |
| Width mm | 13 mm |
| Nominal Length | 14 in. |
| Max Capacity (Pounds) | 100 lbs. |
| Height mm | 46 mm |
| Drainboard Length | 14.5 in. |
| Maximum Drawer Width | 24 in. |
| Minimum Cabinet Depth | 14 in. |
| Minimum Clearance | 0.5 in. |
| Adjustable | No |
| Material | Steel |
| Insulation Type | Side Mount |
| Mounting Type | Side Mount |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Extension Type | 3/4 Extension |
| Soft Close | Yes |
| Self Closing | No |
| Detent | No |
| Disconnect Style | Lever |
| Push to Open | No |
| Slide Type | Ball Bearing |
| Collection | GSlide |
| Manufacturer Warranty | Limited Lifetime |
| Approved for Commercial Use | Yes, No |
| Series | GSlide |
| BHMA Certification | Grade 1 |
| Color | Zinc |
