Features:
Designed to support up to 100 pounds of weight
Mounts to the side of the drawer
Provides easy access to the drawer with full extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Soft Close: Whether large or small, heavy or light, soft closing action keeps drawers from slamming closed. It adapts to various closing speeds and features overload safety to protect the system from damage over time.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 20-1/2″
Slide Length: 20″
Extension Type: Full Extension
Slide Type: Ball Bearing
Weight Capacity: 100 lbs
Material: Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Mounting hardware not included
Product Variations:
GS4270 12: 12 Inch Drawer Slide
GS4270 14: 14 Inch Drawer Slide
GS4270 16: 16 Inch Drawer Slide
GS4270 18: 18 Inch Drawer Slide
GS4270 20 (This Model): 20 Inch Drawer Slide
GS4270 22: 22 Inch Drawer Slide
GS4270 24: 24 Inch Drawer Slide
GS4270 26: 26 Inch Drawer Slide
GS4270 28: 28 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt Gslide Collection
Specifications
| Height | 1.79 in. |
| Width | 0.5 in. |
| Length | 20 in. |
| Nominal Length | 20 in. |
| Quantity | 2 |
| Extension | 20 in. |
| Max Capacity (Pounds) | 100 lbs. |
| Height mm | 46 mm |
| Width mm | 13 mm |
| Minimum Clearance | 0.5 in. |
| Drainboard Length | 20.5 in. |
| Minimum Cabinet Depth | 20 in. |
| Maximum Drawer Width | 24 in. |
| Material | Steel |
| Insulation Type | Side Mount |
| Mounting Type | Side Mount |
| Adjustable | No |
| Extension Type | Full Extension |
| Soft Close | Yes |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Self Closing | No |
| Push to Open | No |
| Detent | No |
| Disconnect Style | Lever |
| Slide Type | Ball Bearing |
| Collection | GSlide |
| Approved for Commercial Use | No, Yes |
| Manufacturer Warranty | Limited Lifetime |
| Series | GSlide |
| BHMA Certification | Grade 1 |
| Color | Zinc |
| Color Tone | Greys |
