Product Features:
Two-piece configuration allows for easier access to the area around the toilet
Elongated bowl offers comfort and convenience, extending out an extra 1-1/2″ compared to a round configuration
Covered under Kohler’s 1 year limited warranty
Constructed of vitreous china providing a classic look and feel
Pressure Lite flush technology provides exception flushing performance with the use of compressed air
ADA compliant – complies with the standards for toilets set forth by the Americans with Disabilities Act
WaterSense certified – toilet uses 20% less water than the current standard while still maintaining superior performance
Concealed trapway – a built in skirt hides the discharge passageway from view, for a smoother, less utilitarian appearance
Product Technologies / Benefits:
Pressure Lite: The Pressure Lite pressure assist flushing system is newly designed to provide exceptional bulk flushing performance through the use of compressed air within the tank reservoir.
Product Specifications:
Overall Height: 31-1/4″ (measured from bottom of base to top of tank)
Overall Depth: 30-1/8″ (measured from back of tank to front of rim)
Overall Width: 21-1/4″ (measured from rightmost to leftmost edge of toilet)
Bowl Height: 17-1/8″ (measured from floor to bowl rim)
Flow Rate: 1 GPF (gallons per flush)
Water Area: 11-1/2″ x 9-1/2″ (inner rim dimensions of bowl, length x width)
Water Depth (from Rim): 5-3/4″
Tank Width: 21-1/4″ (measured from leftmost to rightmost edge of tank)
Tank Depth: 8-5/8″ (measured from back edge to front edge of tank)
Trapway (Discharge Passageway) Size: 2-1/4″
Distance Between Toilet Seat Installation Holes: 5-1/2″
Rough-In: 12″
Â
Additional Kohler Links
View the Manufacturer Warranty
Browse all Kohler Products
Kohler Highline Collection
Specifications
| Depth | 30.125 in. |
| Height | 31.25 in. |
| Width | 21.25 in. |
| Gallons Per Flush | 1 |
| Bowl Height | 17.13 in. |
| Rough In | 12 in. |
| Trapway | 2.25 in. |
| Water Area | 11.50 x 9.50 |
| Material | Vitreous China |
| Thermostat | Basic |
| Insulation Type | Floor Mounted |
| Water Efficient | Yes |
| Configuration | Two Piece |
| Bowl Shape | Elongated |
| Design Features | Chair Height |
| Flush Type | Pressure Assisted |
| Trip Lever Placement | Right |
| Trip Lever Finish | Chrome |
| Approved for Commercial Use | Yes |
| Collection | Highline, Comfort Height |
| ADA | Yes |
| Country Of Origin | USA |
| WaterSense Certified | Yes |
| Made in America | Yes |
| CA Drought Compliant | Yes |
| TX Drought Compliant | Yes |
| Seat Included | No |
| Angle Supply Included | No |
| Color | Almond, Biscuit, Black, Black Black, Ice Grey, Innocent Blush, Mexican Sand, Navy, Sandbar, Seafoam Green, Skylight, Thunder Grey, Timberline, White, Wild Rose |
| Color Tone | Blacks, Greens, Greys, Neutrals, Pinks, Steel Tones, Whites |
