Keyed Entry (Single Cylinder) Function: This single cylinder deadbolt is keyed on the exterior with an associated thumb turn on the inside that can quickly and easily lock or unlock the latch mechanism. Single cylinder locks are most commonly used to secure entrances to a residence or place of business.
Features:
BHMA Grade 1
Designed for left or right handed doors
Includes round, square, and drive in latch to fit all standard doors
Includes round corner deadbolt strike
Adjustable backset to fit all standard door preparations
Lifetime mechanical and finish warranty
Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys
Key Product Attributes:
BumpGuard™: Lock bumping is an attack technique used to defeat conventional pin and tumbler locks. Kwikset’s BumpGuard™ component utilizes a patented side locking bar which replaces the traditional pin and tumbler design providing protection against lock bumping.
SmartKey®:
This technology allows you to re-key your lock in seconds with 3 simple steps and features stainless steel racks, pins, and side locking bar for increased strength and security.
Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/4″
Handing: Reversible
Projection: 0.5″
Latch Faceplate: Round Corner
Cylinder: SmartKey 5 Pin
Additional Kwikset Links
View the Manufacturer Warranty
Browse all Kwikset Products
Kwikset San Clemente Collection
Specifications
| Product Weight | 2.237 lbs. |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Backset | Adjustable 2-3/8" or 2-3/4" |
| Cross Bore | 2-1/8" |
| Edge Bore | 1" |
| Interior Height | 3.5625 in. |
| Interior Width | 2.75 in. |
| Exterior Height | 3.5625 in. |
| Exterior Projection | 0.5625 in. |
| Exterior Width | 2.75 in. |
| Interior Projection | 1.65 in. |
| Material | Zinc |
| Thermostat | Contemporary |
| Handshower | Left, Reversible, Right |
| Function | Keyed Entry |
| Cylinder Type | Single Cylinder |
| Panic Proof | No |
| Concealed Screws | No |
| Keyway | KW1 |
| Latch Faceplate | Drive-In, Round Corner, Square Corner |
| Rosette Shape | Rectangle |
| Cylinder | SmartKey 5 Pin |
| Number of Keys | 2 |
| Collection | San Clemente |
| Approved for Commercial Use | No |
| Certifications | ANSI, BHMA |
| Country Of Origin | Taiwan |
| Fire Rated | No |
| Manufacturer Warranty | Limited Lifetime |
| ANSI Certification | A156.36 |
| BHMA Certification | Grade 1 |
| ADA | Yes |
| Series | Signature |
| Color | Bright Chrome, Matte Black, Satin Brass, Satin Nickel |
| Color Tone | Blacks, Brass Tones, Nickel Tones, Silver Tones |
