PLEASE NOTE: When selecting Keying Options above, this item is treated as two separate items. By selecting “Keyed Alike” the handle and deadbolt will be keyed alike. Selecting “Keyed Differently” the handle and deadbolt will be keyed to two different keys. When ordering multiple combo packs on the same order, “Keyed Alike” means every handle and deadbolt will be keyed to the same key. “Keyed Differently” means every handle and deadbolt will be keyed to different keys. If you require different groups of combo packs to be “Keyed Alike”, separate orders will be required. Please contact customer service if you need help determining your needs.
Single Cylinder Function: Single cylinder deadbolts are keyed on the exterior with an associated thumb turn on the inside that can quickly and easily lock or unlock the latch mechanism. Single cylinder locks are most commonly used to secure entrances to a residence or place of business.
Lever Keyed Entry (Single Cylinder) Function: Single cylinder keyed entry door hardware is locked and unlocked from the exterior using a key and can be locked and unlocked from the interior using the locking mechanism. Perfect for securing entrances, side doors, and anywhere else that needs a bit more security.
Lever Features:
Leverset and deadbolt both exceed ANSI/BHMA security standards
All metal construction for long-lasting durability and a premium feel
Handing is reversible for either left or right door configurations
Deadbolt and dead latch are 6 way adjustable
Installs easily into most standard prepared doors
Lifetime mechanical and finish warranty
Deadbolt Features:
BHMA Grade 1
Designed for left or right handed doors
Includes round, square, and drive-in latch to fit all standard doors
Includes round corner deadbolt strike
Adjustable backset to fit all standard door preparations
Lifetime mechanical and finish warranty
Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys
Key Product Attribute:
SmartKey®:Â
This technology allows you to re-key your lock in seconds with 3 simple steps and features stainless steel racks, pins, and side locking bar for increased strength and security.
Lever Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Latch Faceplate: Round Corner, Square Corner, Drive-In
Cylinder: SmartKey 5 Pin
Deadbolt Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Cylinder: SmartKey 5 Pin
Additional Kwikset Links
View the Manufacturer Warranty
Browse all Kwikset Products
Kwikset Ladera Collection
Specifications
| Material | Brass, Zinc |
| Concealed Screws | No |
| Function | Keyed Entry |
| Handshower | Left, Reversible, Right |
| Handle Design | Ladera |
| Handle Material | Metal |
| Handle Style | Lever |
| Latch Faceplate | Drive-In, Round Corner, Square Corner |
| Rosette Shape | Round |
| Thermostat | Contemporary |
| Keyway | KW1 |
| Cylinder Type | Single Cylinder |
| Lever Shape | Square, Straight |
| Panic Proof | No |
| Lock Style | Two Point |
| Cylinder | SmartKey 5 Pin |
| ADA | Yes |
| Approved for Commercial Use | No |
| Certifications | ANSI, UL |
| Collection | Ladera |
| Fire Rated | Yes |
| Manufacturer Warranty | Limited Lifetime Finish, Limited Lifetime Mechanical |
| Series | Signature Series, Contemporary |
| ANSI Certification | A156.2, A156.36 |
| BHMA Certification | Grade 1, Grade 3 |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Cross Bore | 1-1/2", 2-1/8" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Edge Bore | 1" |
| Handle Projection | 2.4375 in. |
| Product Weight | 4 lbs. |
| Trim Height | 2.625 in. |
| Trim Width | 2.625 in. |
| Handle Length | 4.1875 in. |
| Cylinder Included | Yes |
| Color | Satin Nickel, Venetian Bronze |
