Passage: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock isn’t needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.
Â
Features:
Tested to exceed ANSI/BHMA Grade 3 security requirements
Constructed of high quality materials for durability and dependability
Installs easily with all necessary mounting hardware included
Covered by Kwikset’s limited lifetime manufacturer warranty
ADA compliant
UL certified
Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Handle Length: 3-5/8″
Handle Projection: 2-3/8″
Trim Width: 2-9/16″
Trim Height: 2-9/16″
Product Weight: 2.209 lbs.
Latch Faceplate: Round Corner
Additional Kwikset Links
View the Manufacturer Warranty
Browse all Kwikset Products
Kwikset Winston Collection
Specifications
| Material | Zinc |
| Thermostat | Contemporary |
| Rosette Shape | Round |
| Handle Material | Metal |
| Handle Style | Lever |
| Concealed Screws | No |
| Function | Passage |
| Handshower | Left, Reversible, Right |
| Latch Faceplate | Round Corner |
| Lever Shape | Flat, Straight |
| Handle Design | Winston |
| Collection | Safe Lock |
| Approved for Commercial Use | No |
| ADA | Yes |
| Country Of Origin | Philippines |
| Certifications | ANSI, BHMA, UL |
| Manufacturer Warranty | Limited Lifetime |
| Fire Rated | Yes |
| Series | Winston |
| BHMA Certification | Grade 3 |
| ANSI Certification | A117.1 |
| Product Weight | 2.209 lbs. |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Handle Projection | 2.375 in. |
| Trim Height | 2.5625 in. |
| Trim Width | 2.5625 in. |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Edge Bore | 1" |
| Handle Length | 3.625 in. |
| 28 Degree Latch | No |
| Color | Bright Brass, Matte Black, Satin Chrome, Satin Nickel, Venetian Bronze |
| Color Tone | Blacks, Brass Tones, Bronze Tones, Nickel Tones, Silver Tones |
