Mansfield 130LTCTK Features:
Two-piece configuration allows for easier access to the area around the toilet
Covered under a limited lifetime warranty
Constructed of vitreous china, ensuring durability and dependability
Round bowl is ideal for baths with limited space
Complete toilet package includes toilet seat, wax ring, floor bolts and caps
For floor mounted installations
Insulated tank – prevents condensate from forming on the outside of the toilet tank and ending up on the floor
Mansfield 130LTCTK Specifications:
Overall Height: 29-7/8″ (bottom of the base to the highest point on the toilet)
Overall Depth: 26-3/4″ (back of the tank to the front of the rim)
Overall Width: 19-3/4″ (furthest point on the left to the furthest on the right)
Bowl Height: 15-1/8″ (bottom of the base to the rim)
Flow Rate: 1.6 gallons-per-flush
Water Area: 8″ x 9″
Trapway (Discharge Passageway) Size: 2″
Rough-In: 12″
Distance Between Toilet Seat Installation Holes: 5-1/2″
Additional Mansfield Links
Browse all Mansfield Products
Mansfield Pro-Fit Collection
Specifications
| Height | 29.875 in. |
| Product Weight | 85 lbs. |
| Width | 19.75 in. |
| Depth | 26.75 in. |
| Hinge Center to Center | 5.5 in. |
| Bowl Height | 15.125 in. |
| Flush Valve Size | 2 in. |
| Gallons Per Flush | 1.6 |
| Rough In | 12 in. |
| Trapway | 2 in. |
| Water Area | 8 x 9 |
| Material | Vitreous China |
| Thermostat | Contemporary |
| Insulation Type | Floor Mounted |
| Bowl Shape | Round |
| Design Features | Insulated Tank, Glazed Trapway |
| Configuration | Two Piece |
| Flush Type | Gravity Flush |
| Trip Lever Placement | Left |
| ADA | No |
| Certifications | UPC, ASME, CSA |
| Collection | Pro-Fit |
| ASSE Code | A112.19.2 |
| CA Drought Compliant | No |
| Country Of Origin | USA |
| Manufacturer Warranty | Limited Lifetime |
| WaterSense Certified | No |
| Made in America | Yes |
| TX Drought Compliant | No |
| CSA Code | B45.1 |
| Seat Included | Yes |
| Color | White |
| Color Tone | Whites |
