Features:
Includes one (1) door hinge in each order
Features square corners
Hinge is designed with a non removable pin
Constructed from steel for long lasting durability
Exceeds criteria for BHMA Grade 1 certification
Non-handed for left or right handed door applications
Accomodates doors of 1-3/4″ thickness
Mckinney offers a limited 1 year manufacturer warranty
Tested for commercial strength, ideal for heavy duty applications
Product Technologies:
Ball Bearing Hinge: Ball bearing hinges are designed to handle the extra stress brought on by high traffic doorways. The greased bearings reduce the rotational friction extending the life of a hinge in heavy use situations. These hinges tend to be more durable than standard, or plain bearing hinges.
Mortise Hinge: Mortise door hinges mount flush with the surface of your door, providing maximum strength with the least interference with door functionality. It is recommended that three hinges be used on doors up to and including 7-1/2 feet, with one additional hinge for each additional 2-1/2 feet. Be sure to check your current hinges before making a purchase.
Specifications:
Height: 4-1/2″
Width: 4-1/2″
Material: Steel
Mount Type: Mortise
Gauge (Thickness of Hinge): 0.134″
Number of Knuckles: 5
Number of Holes: 8
Removable Pin: No
Door Thickness: 1-3/4″
Quantity: 1
Additional McKinney Links
Browse all McKinney Products
McKinney MPB68 Collection
Specifications
| Height | 4.5 in. |
| Width | 4.5 in. |
| Door Thickness | 1-3/4" |
| Gauge | 0.134 |
| Quantity | 1 |
| Corners | Square Corner |
| Hinge Size | 4-1/2 x 4-1/2 in. |
| Approved for Commercial Use | Yes |
| Collection | MPB68 |
| Manufacturer Warranty | 1 Year Limited |
| Series | MacPro |
| Certifications | ANSI |
| ANSI Certification | A156.1 |
| BHMA Certification | Grade 1 |
| Usage Level | Commercial Grade |
| Insulation Type | Screw |
| Material | Steel |
| Mounting Type | Mortise |
| Adjustable | No |
| Hole Pattern | Arc |
| Number Of Hooks | 8 |
| Number of Knuckles | 5 |
| Removable Pin | No |
| Sconce Type | Wood/Machine |
| Self Closing | No |
| Hinge Type | Ball Bearing |
| Color | Satin Chrome |
| Color Tone | Silver Tones |
