Features:
Includes one (1) door hinge in each order
Features square corners
Hinge is designed with a removable pin
Constructed from steel for long lasting durability
Non-handed for left or right handed door applications
Accomodates doors of 1-3/4″ thickness
Mckinney offers a limited 1 year manufacturer warranty
Tested for commercial strength, ideal for standard duty applications
Template Screw Pattern
Product Technologies:
Ball Bearing Hinge: Ball bearing hinges are designed to handle the extra stress brought on by high traffic doorways. The greased bearings reduce the rotational friction extending the life of a hinge in heavy use situations. These hinges tend to be more durable than standard, or plain bearing hinges.
Mortise Hinge: Mortise door hinges mount flush with the surface of your door, providing maximum strength with the least interference with door functionality. It is recommended that three hinges be used on doors up to and including 7-1/2 feet, with one additional hinge for each additional 2-1/2 feet. Be sure to check your current hinges before making a purchase.
Specifications:
Height: 4-1/2″
Width: 4-1/2″
Material: Steel
Mount Type: Mortise
Gauge (Thickness of Hinge): 0.134″
Number of Knuckles: 5
Number of Holes: 8
Removable Pin: Yes
Door Thickness: 1-3/4″
Quantity: 1
Additional McKinney Links
Browse all McKinney Products
McKinney TA2714 Collection
Specifications
| Width | 4.5 in. |
| Height | 4.5 in. |
| Quantity | 1 |
| Door Thickness | 1-3/4" |
| Gauge | 0.134 |
| Corners | Square Corner |
| Hinge Size | 4-1/2 x 4-1/2 in. |
| Collection | TA2714 |
| Certifications | ANSI |
| Manufacturer Warranty | 1 Year Limited |
| Approved for Commercial Use | Yes |
| ANSI Certification | A156.1 |
| Usage Level | Commercial Grade |
| Material | Steel |
| Insulation Type | Screw |
| Mounting Type | Mortise |
| Adjustable | No |
| Self Closing | No |
| Hinge Type | Ball Bearing |
| Hole Pattern | Template |
| Number Of Hooks | 8 |
| Number of Knuckles | 5 |
| Removable Pin | Yes |
| Sconce Type | Wood/Machine |
| Color | Black Powder Coat, Bright Brass, Bright Chrome, Oil Rubbed Bronze, Prime Coat, Satin Brass, Satin Bronze, Satin Chrome, Satin Nickel |
| Color Tone | Blacks, Brass Tones, Bronze Tones, Nickel Tones, Silver Tones, Whites |
