Features:
Includes one (1) door hinge in each order
Features square corners
Hinge is designed with a non removable pin
Constructed from brass for long lasting durability and beauty
Exceeds criteria for BHMA Grade 2 certification
Handing is designed for left handed door applications
Accomodates doors of 1-3/8″ to 1-3/4″ thickness
Mckinney offers a limited 1 year manufacturer warranty
Tested for commercial strength, ideal for light duty applications
Product Technologies:
Mortise Hinge: Mortise door hinges mount flush with the surface of your door, providing maximum strength with the least interference with door functionality. It is recommended that three hinges be used on doors up to and including 7-1/2 feet, with one additional hinge for each additional 2-1/2 feet. Be sure to check your current hinges before making a purchase.
Specifications:
Height: 6″
Width: 3-7/8″
Material: Brass
Mount Type: Mortise
Gauge (Thickness of Hinge): 0.203″
Number of Knuckles: 2
Number of Holes: 8
Removable Pin: No
Door Thickness: 1-3/8″ to 1-3/4″
Quantity: 1
Additional McKinney Links
Browse all McKinney Products
McKinney TA338 Collection
Specifications
| Height | 6 in. |
| Width | 3.875 in. |
| Gauge | 0.203 |
| Quantity | 1 |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Corners | Square Corner |
| Collection | TA338 |
| Manufacturer Warranty | 1 Year Limited |
| Approved for Commercial Use | Yes |
| ANSI Certification | A156.1 |
| BHMA Certification | Grade 2 |
| Usage Level | Commercial Grade |
| Material | Brass |
| Insulation Type | Screw |
| Handshower | Left |
| Mounting Type | Mortise |
| Adjustable | No |
| Self Closing | No |
| Number Of Hooks | 8 |
| Number of Knuckles | 2 |
| Removable Pin | No |
| Sconce Type | Wood/Machine |
| Color | Bright Brass |
| Color Tone | Brass Tones |
