Product Features:
Faucet body constructed of brass
Covered under Moen’s 5 year limited commercial faucet warranty
Premier finishing process – finishes will resist corrosion and tarnishing through everyday use
Handles include temperature indicator decals
Includes vandal-resistant Torx head screws and aerator
Double handle operation – handles rest on 1/4 turn valves
ADA compliant – complies with the standards set forth by the Americans with Disabilities Act for bathroom faucets
Low lead compliant – meeting federal and state regulations for lead content
Complete with ceramic disc valve
Designed for use with standard U.S. plumbing connections
All hardware needed for mounting is included with faucet
Product Specifications:
Overall Height: 4-3/16″ (measured from counter top to highest part of faucet)
Spout Height: 2-7/8″ (measured from counter top to spout outlet)
Spout Reach: 4-5/8″ (measured from center of faucet base to center of spout outlet)
Number of Faucet Holes Required for Installation: 3
Faucet Centers (Distance Between Handle Installation Holes): 8″
Flow Rate: 0.5 GPM (gallons-per-minute)
Maximum Deck Thickness: 1-1/2″
2 handles included with faucet
Valve Type: Ceramic disc
Variations:
8228F05: This model
8228: This model with 2.2 GPM flow rate
8228F03: This model with 0.35 GPM flow rate
8228F15: This model with 1.5 GPM flow rate
Additional Moen Links
View the Manufacturer Warranty
Browse all Moen Products
Moen M-Dura Collection
Specifications
| Height | 4.75 in. |
| Width | 15.75 in. |
| Faucet Centers | 8 in. |
| Flow Rate (GPM) | .5 |
| Water Connection | 1/2" |
| Faucet Hole Size | 1.06 in. |
| Handle Height | 4.75 in. |
| Max Deck Thickness | 1.5 in. |
| Spout Height | 2.875 in. |
| Spout Reach | 4.625 in. |
| Insulation Type | Deck Mounted |
| Material | Brass |
| Thermostat | Basic |
| Faucet Holes | 3 |
| Mounting Type | Widespread |
| Faucet Type | Bathroom Sink Faucet |
| Handle Style | Wrist Blade |
| Number Of Handles | 2 |
| Spout Style | Conventional |
| Spout Type | Fixed |
| Valve Type | Ceramic Disc |
| Handle Material | Metal |
| Vandal Resistant | Yes |
| ADA | Yes |
| Collection | M-DURA |
| Approved for Commercial Use | Yes |
| Country Of Origin | USA |
| Manufacturer Warranty | 5 Year Limited |
| ASSE Code | A112.18.1 |
| Certifications | ASME, CSA, NSF |
| CA Drought Compliant | Yes |
| Lead Leaching Certified NSF/ANSI 61 | Yes |
| Low Lead Compliant | Yes |
| CSA Code | B125.1 |
| Eco Friendly | Yes |
| WaterSense Certified | No |
| Drain Assembly Included | No |
| Handshower Included | Yes |
| Soap Dispenser Included | No |
| Valve Included | Yes |
| Pop-Up Included | No |
| Color | Chrome |
| Color Tone | Silver Tones |
