Features:
Hardened steel rack and pinion mechanism offer long life and durability
Adjustable back check, closing and latch speeds allow you to customize the entire door opening cycle to fit your requirements
Optional delay action must be purchased seperately
Heavy duty cast iron body with rust-inhibiting treatment
Plastic cover protects the body of the door closer from the elements
Regular and parallel bracket come standard for non-handed installation
Comes with wood and machine screws for installation in wood or metal doors
Multi-size strength, power adjustable for size 1 through 6
25 year limited mechanical and 5 year finish warranty
Specifications:
Door Weight: 44 to 265 lbs
Cover Material: Plastic
Body Material: Cast Iron
Arm Material: Steel
UL Listed: Yes
BHMA Certification:Â Grade 1
Length: 11″
Height: 2-3/4″
Additional Pamex Links
Browse all Pamex Products
Pamex GC4400 Collection
Specifications
| Approved for Commercial Use | Yes |
| Manufacturer Warranty | 25 Year Mechanical, 5 Year Finish |
| Collection | GC4400 |
| Certifications | UL |
| ADA | Yes |
| BHMA Certification | Grade 1 |
| Usage Level | Heavy Duty |
| Installation Hardware Included | Yes |
| Cushion Stop | No |
| Material | Cast Iron, Plastic, Steel |
| Handshower | Left, Reversible, Right |
| Adjustable Backcheck | Yes |
| Adjustable Spring | Yes |
| Arm Type | Standard |
| Barrier Free | Yes |
| Delay Action | No |
| Hold Open | No |
| Mounting | Regular |
| Operation Mode | Hydraulic |
| Shell Material | Plastic |
| Height | 2.75 in. |
| Closer Body Length | 11 in. |
| Closer Size | 1-6, 1, 2, 3, 4, 5, 6 |
| Max Door Weight | 265 lbs. |
| Adjustable Closing Speed | Yes |
| Adjustable Latching Speed | Yes |
| Color | Aluminum, Dark Brown |
| Color Tone | Neutrals |
