Features:
Includes two hinges in each order
All metal construction ensures durability and quality
Smooth and quiet soft-close mechanism
All necessary mounting hardware is included
Specifications:
Cup Diameter: 35 mm
Cup Depth: 11 mm
Hinge Mount: Partial Overlay
Opening Angle: 110°
Material: Zinc
Mount Type: Screw-In
Additional Richelieu Links
Browse all Richelieu Products
Richelieu FGV Collection
Specifications
Characteristics and Features
| Material | Zinc |
| Insulation Type | Screw |
| Soft Close | Yes |
| Cabinet Type | Panel (Frameless) |
| Adjustable Height | Yes |
| 3-Way Adjustable | Yes |
| Adjustable Depth | Yes |
| Adjustable Side to Side | Yes |
| Arm Type | Half Cranked |
| Hinge Mount | Partial Overlay |
| Hinge Type | Concealed Euro |
| Self Closing | No |
| Soft Close Deactivation | No |
Warranty and Product Information
| Collection | FGV |
| Approved for Commercial Use | No |
| Country Of Origin | China |
Included Components
| Installation Hardware Included | Yes |
Dimensions and Measurements
| Quantity | 2 |
| Opening Angle | 110 |
| Cup Depth | 11 in. |
| Cup Diameter | 35 in. |
| Max Cabinet Door Thickness | 1 in. |
| Max Cabinet Door Thickness mm | 26 mm |
| Overlay | 1/2 Inch |
