Single Cylinder Keyed Entry Function: Single cylinder keyed entry door hardware is locked and unlocked from the exterior using a key and can be locked and unlocked from the interior using the locking mechanism. Perfect for securing entrances, side doors, and anywhere else that needs a bit more security.
Features:
Exceeds criteria for BHMA Grade 2 certification
Durable construction for lasting use
Installs on doors with 1-3/8″ to 1-3/4″ thickness
Schlage offers a 10 Year limited warranty
Complies with standards of the Americans with Disabilities Act (ADA)
Fireproof for up to 3 hours when installed on fireproof door
Specifications:
Backset: 2-3/4″, 2-3/8″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Handle Length: 5-13/16″
Handle Projection: 3-1/4″
Trim Width: 3-7/16″
Trim Height: 3-7/16″
Product Weight: 4 lbs.
Latch Faceplate: Square Corner
Cylinder: 5 Pin C Keway
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage ALX Collection
Specifications
| Backset | 2-3/4", 2-3/8" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Edge Bore | 1" |
| Handle Projection | 3.25 in. |
| Trim Height | 3.4375 in. |
| Trim Width | 3.4375 in. |
| Product Weight | 4 lbs. |
| Handle Length | 5.8125 in. |
| Cylinder Included | Yes |
| Cylinder | 5 Pin C |
| Cylinder Type | Single Cylinder |
| Function | Keyed Entry, Office |
| Handshower | Left, Reversible, Right |
| Handle Style | Lever |
| Keyway | C |
| Latch Faceplate | Square Corner |
| Material | Zinc |
| Thermostat | Contemporary |
| Concealed Screws | Yes |
| Handle Material | Metal |
| Lever Shape | Straight |
| Rosette Shape | Round |
| Approved for Commercial Use | Yes |
| BHMA Certification | Grade 2 |
| Collection | Saturn |
| Series | ALX |
| ADA | Yes |
| Manufacturer Warranty | 10 Year Limited |
| Certifications | UL |
| ANSI Certification | A156.2 |
| Country Of Origin | Mexico, USA |
| Made in America | Yes |
| Fire Rated | Yes |
| Color | Matte Black |
| Color Tone | Blacks |
