Features:
Standalone, offline, manually programmable lock
All user rights are stored on the lock
Normal, toggle, pass through, and freeze credential attributes available
12 button keypad compatible with 3-6 digit PIN codes
Meets requirements for ANSI A156.25 and BHMA Grade 1 certifications
Mechanical key override is standard and compatible with multiple cylinder types
Two year battery life using standard AA batteries, provides low battery warning
Exit trim designed to work with the following exit device series:
Von Duprin 98 / 99 and 98 / 99 XP Rim and Concealed Vertical Rod
Von Duprin 22 / 22F
Falcon 25
Corbin Russwin 5000M
Precision 21 (Rim 2100 converts to 21 with Precision’s BP21 kit)
Yale 7000
Dorma 9300
Sargent 80
Specifications:
Backset: 2-3/8″, 2-3/4″, 3-3/4″, 5″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/4″ to 2-3/4″
Handing: Reversible Left or Right
Cylinder: 6 Pin Schlage C Keyway
Height: 9.46″
Width: 3.44″
Projection: 3.67″
Maximum Users: 500
Credential Verification Time: Less Than 1 Second
Operating Temperature – Exterior: -31 to 151F (-35 to 66C)
Operating Temperature – Interior: 32 to 120F (0 to 49C) due to battery
Operating Humidity: 0 – 100% condensing
Strike: 4-7/8″ x 1-1/4″ Square Corner T Strike with 1-3/16″ Curved Lip
Latch: 1-1/8″ x 2-1/4″ Square Corner Faceplate, 1/2″ Throw
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage CO-100 Series Collection
Specifications
| Approved for Commercial Use | Yes |
| Collection | CO-Series, Rhodes |
| Series | CO-Series |
| ADA | Yes |
| ANSI Certification | A156.25 |
| Certifications | ANSI, UL |
| BHMA Certification | Grade 1 |
| Height | 9.46 in. |
| Width | 3.44 in. |
| Backset | 2-3/4", 2-3/8", 3-3/4", 5" |
| Door Thickness | 1-3/4", 1-7/8", 2", 2-1/2", 2-1/4", 2-1/8", 2-3/4", 2-3/8", 2-5/8" |
| Projection | 3.67 in. |
| Handle Style | Lever |
| Function | Office, Keyless Entry, Electronic Keyless Entry |
| Keyway | C123 |
| Latch Faceplate | Square Corner |
| Handshower | Left, Right |
| Handle Material | Metal |
| Auto-Lock Capable | Yes |
| Cylinder Type | Single Cylinder |
| Insulation Type | Keypad |
| Lit Keypad | No |
| Number of Codes | 500 |
| Remote Access | No |
| Temporary Access | Yes |
| Usage Monitoring | No |
| Cylinder | 6 Pin Schlage C |
| Handle Design | Rhodes |
| Temperature (Max) | 120, 151 °F |
| Temperature (Min) | -31, 32 °F |
| Color | Aged Bronze, Satin Bronze, Satin Chrome |
| Color Tone | Bronze Tones, Silver Tones |
