Features:
Standalone, offline, manually programmable lock
User rights stored on the lock
Normal, toggle, pass through, and freeze credential attributes available
Keypad
ANSI A156.25 / BHMA Grade 1
Mechanical key override is standard and compatible with multiple cylinder types
Up to a two year battery life with standard off the shelf AA batteries, provides low battery warning
Cylindrical (Tubular) locking mechanism
Schlage key-in-lever 6 pin cylinder
12 button keypad compatible with 3-6 digit PIN codes
Sparta Style Lever
Specifications:
Maximum Users: 500
Credential Verification Time: Less Than 1 Second
Operating Temperature – Exterior: -31 to 151F (-35 to 66C)
Operating Temperature – Interior: 32 to 120F (0 to 49C) due to battery
Operating Humidity: 0 – 100% condensing
Exterior Dimensions:
Height: 9.46″
Width: 3.44″
Projection: 3.67″
Interior Dimensions:
Height: 10.1″
Width: 3.44″
Projection: 2.96″
Door Thickness: 1-3/8″ to 2-3/4″
Backset Options: 2-3/8″, 2-3/4″, 3-3/4″, 5″
Strike: 4-7/8″ x 1-1/4″ Square Corner T Strike with 1-3/16″ Curved Lip
Latch: 1-1/8″ x 2-1/4″ Square Corner Faceplate, 1/2″ Throw
There are industry standards, and then there are Schlage standards. If it has the Schlage name on it, you can be sure they put it through more punishment than you ever will. Schlage has a rich history in security. For over 90 years they’ve endeavored to develop a complete line-up of security solutions you can trust. Simply put, they believe everyone deserves peace of mind, every day.
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage CO-100 Series Collection
Specifications
| Material | Zinc |
| Thermostat | Modern |
| Handle Material | Metal |
| Keyway | C123 |
| Function | Office, Keyless Entry, Electronic Keyless Entry |
| Handshower | Left, Right |
| Latch Faceplate | Square Corner |
| Handle Design | Sparta |
| Cylinder | 6 Pin Schlage C |
| Cylinder Type | Single Cylinder |
| Auto-Lock Capable | Yes |
| Insulation Type | Keypad |
| Lit Keypad | No |
| Number of Codes | 500 |
| Usage Monitoring | No |
| Remote Access | No |
| Power Source | Battery |
| Temperature (Max) | 120, 151 °F |
| Temperature (Min) | -31, 32 °F |
| Collection | CO-Series, Sparta |
| Approved for Commercial Use | Yes |
| ADA | Yes |
| Certifications | ANSI, UL |
| Series | CO-Series |
| BHMA Certification | Grade 1 |
| ANSI Certification | A156.25 |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8", 2", 2-1/4", 2-3/4", 2-3/8", 2-5/8" |
| Handle Height | 9.46 in. |
| Handle Projection | 3.67 in. |
| Backset | 2-3/4", 2-3/8", 5" |
| Handle Length | 4.9375 in. |
| Handle Width | 3.44 in. |
| Interchangeable Core | No |
| Color | Satin Chrome |
| Color Tone | Silver Tones |
