Double Cylinder Heavy Duty Vestibule Knob set Door Lock from the Tulip Collection
This knob set is unlocked by a key from the outside when the outside knob is locked by a key from the inside. The inside knob is always unlocked
Latch: 1 1/8″ x 2 1/4″, Square corner faceplate, 1″ housing diameter, 1/2″ throw
Strike: 1 1/4″ x 4 7/8″, ANSI Square corner, no box
Cylinder: 6-Pin solid brass, keyed 6-pin, c123 keyway
Door range: 1 3/8″ – 2″
Caution: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times or emergency and their use is not recommended. Installation should be in accordance with existing codes only.
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage D-Series Collection
Specifications
| Thermostat | Transitional |
| Style | Commercial |
| Handle Material | Metal |
| Cylinder Type | Double Cylinder |
| Function | Keyed Entry, Vestibule |
| Handshower | Left, Reversible, Right |
| Knob Shape | Tulip |
| Latch Faceplate | Square Corner |
| Rosette Shape | Round |
| Cylinder | 6 Pin Schlage C |
| Panic Proof | Yes |
| Keyway | C123 |
| Handle Design | Tulip |
| Mortise | No |
| ADA | No |
| Approved for Commercial Use | Yes |
| Manufacturer Warranty | 3 Year Limited |
| Collection | Tulip |
| Series | D-Series |
| Certifications | ANSI, UL |
| ANSI Certification | A156.12 |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
| Backset | 2-3/4" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8", 1-7/8", 2" |
| Edge Bore | 1" |
| Interchangeable Core | No |
| Color | Antique Brass |
| Color Tone | Brass Tones |
