Decidedly modern, Schlage’s Broadway door lever provides a soft, yet iconic new face to contemporary décor, proving once again that simplicity and style can easily go hand in hand. Constructed from quality materials, and designed to be quickly and easily installed, Schlage F-Series levers also feature BHMA Grade 2 certification, the highest performance rating awarded to residential lever sets. Schlage believes that you should never have to choose between security and aesthetics—with the Broadway lever you can sleep sound knowing that you’ve received the best of both worlds.
Features:
BHMA Grade 2, The Highest Residential Security Rating for a Lever Product
Constructed from High Quality Materials with both Security and Durability in Mind
Features a Reversible, Symmetrical Design for Right or Left Handed Doors
Simple Three Step Installation is Guaranteed to Fit on Standard Pre-Drilled Doors
Includes Round Corner and Drive-In Latch Faceplate Options for Maximum Versatility
Limited Lifetime Finish and Mechanical Warranty
Complies with ADA Accessibility Guidelines
Featured Technologies:
Passage Function: Schlage’s passage door lever sets have no locking function and are free turning on both sides. These levers are perfect for a hallway or closet where a lock isn’t necessary. Passage levers can also be used in conjunction with a deadbolt to secure an entrance or back door.
Specifications:
Backset: Adjustable to 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 7/8″
Door Thickness: 1-3/8″ or 1-3/4″
Handing: Reversible
Lever Length: 3-6/7″
Projection: 2-3/8″
Product Weight: 1.55 Lbs
Additional Functions:
F40-BRW-GRW: Privacy Door Lever Set
F170-BRW-GRW: Single Dummy Door Lever Set
F51-BRW-GRW: Single Cylinder Keyed Entry Door Lever Set
F54-BRW-GRW: Single Cylinder Fixed Interior Door Lever Set
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage Greenwich Collection
Specifications
| Thermostat | Modern |
| Handshower | Left, Right |
| Handle Material | Metal |
| Latch Faceplate | Drive-In, Round Corner |
| Style | Contemporary / Modern |
| Concealed Screws | No |
| Function | Passage |
| Rosette Shape | Rectangle |
| Panic Proof | Yes |
| Lever Shape | Round, Straight |
| Handle Design | Broadway |
| Approved for Commercial Use | No |
| ADA | Yes |
| Collection | F-Series |
| Certifications | ANSI, UL |
| ANSI Certification | A156.5 |
| Series | F-Series |
| BHMA Certification | Grade 2 |
| Product Weight | 1.55 lbs. |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Edge Bore | 7/8" |
| Door Thickness | 1-3/4" |
| Cross Bore | 2-1/8" |
| Handle Projection | 2.375 in. |
| Handle Length | 3.85 in. |
| Color | Aged Bronze, Bright Chrome, Matte Black, Satin Chrome, Satin Nickel |
| Color Tone | Blacks, Bronze Tones, Nickel Tones, Silver Tones |
