Features:
Tested to exceed ANSI/BHMA Grade 2 security requirements
Constructed of high quality materials for durability and dependability
Installs easily with all necessary mounting hardware included
Covered by Schlage’s limited lifetime manufacturer warranty
ADA compliant
Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Handle Length: 3-7/8″
Handle Projection: 1-11/16″
Trim Width: 2-3/4″
Trim Height: 2-3/4″
Product Weight: 1.59 lbs.
Latch Faceplate: Round Corner
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage Delfayo Collection
Specifications
Characteristics and Features
| Thermostat | Contemporary |
| Function | Privacy |
| Material | Zinc |
| Handshower | Left, Reversible, Right |
| Locking Mechanism | Push Button |
| Handle Style | Lever |
| Concealed Screws | No |
| Handle Material | Metal |
| Handle Design | Delfayo |
| Latch Faceplate | Round Corner |
| Trim Design | Plymouth |
| Rosette Shape | Round |
| Lever Shape | Straight |
Warranty and Product Information
| Certifications | ANSI, BHMA |
| Collection | Delfayo |
| Series | F-Series |
| Approved for Commercial Use | No |
| ADA | Yes |
| Country Of Origin | Mexico |
| Manufacturer Warranty | Limited Lifetime |
| Fire Rated | No |
| ANSI Certification | A156.2, A156.39 |
| BHMA Certification | Grade 2 |
Dimensions and Measurements
| Product Weight | 1.59 lbs. |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Cross Bore | 2-1/8" |
| Edge Bore | 1" |
| Handle Projection | 1.67 in. |
| Trim Height | 2.75 in. |
| Trim Width | 2.75 in. |
| Handle Length | 3.86 in. |
| Color | Aged Bronze, Bright Chrome, Matte Black, Satin Brass, Satin Nickel |
