Privacy Function: Privacy door hardware features a push-button locking mechanism on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side features a small pin hole to unlock the door hardware from the outside.
Â
Features:
Meets ANSI/BHMA Grade 2 security standards
Constructed from the finest materials for durability along with quality
This lever set is reversible for left or right handed configurations
Guaranteed Lifetime Mechanical and Finish Warranty for the original purchaser
This product is ADA compliant
Product Technologies:
BHMA/ANSI Grade 2 certified which indicates excellent performance across a range of residential applications. This product is built from high-quality materials to give you exceptional security.
Installation is easy, all you need is a screwdriver and a little time. The set is designed to fit standard prep doors and most installations should take less than an hour.
A Lifetime Mechanical and Finish Warranty gives you the piece of mind that this product will be looking good and functioning smoothly for as long as you own it.(Finish warranty does not include Oil Rubbed Bronze because it is a living finish and it is expected to patina over time).
These levers are field reversible allowing this lever set to be used for both right and left handed applications with ease and eliminating any chance of getting a wrong handed product.
Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 7/8″ or 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Lever Length: 4-1/2″
Projection: 2-1/4″
Latch Faceplate: Round Corner, Square Corner or Drive-In
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage F-Series Collection
Specifications
| Thermostat | Transitional |
| Handle Material | Metal |
| Handshower | Left, Right |
| Function | Privacy |
| Latch Faceplate | Drive-In |
| Lever Shape | Designer, Straight |
| Rosette Shape | Rectangle |
| Trim Design | Century |
| Handle Design | Merano |
| Locking Mechanism | Push Button |
| ADA | Yes |
| Manufacturer Warranty | Limited Lifetime Finish, Limited Lifetime Mechanical |
| Collection | Decorative Collection, Merano |
| Certifications | ANSI |
| Approved for Commercial Use | No |
| Series | Decorative Collection, F-Series |
| ANSI Certification | A156.5 |
| BHMA Certification | Grade 2 |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Cross Bore | 2-1/8" |
| Edge Bore | 1", 7/8" |
| Handle Length | 4.125 in. |
| Handle Projection | 2.625 in. |
| Color | Aged Bronze, Bright Chrome, Matte Black, Satin Chrome, Satin Nickel |
| Color Tone | Blacks, Bronze Tones, Nickel Tones, Silver Tones |
