Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys
Keyed Entry (Single Cylinder) Function: This lever set is locked and unlocked from the exterior using a key and can be locked and unlocked from the interior using the thumbturn located on the lever. Perfect for securing entrances, side doors, and anywhere else that needs a bit more security.
Product Features:
A Lifetime Mechanical and Finish Warranty gives you the peace of mind that this product will be looking good and functioning smoothly for as long as you own it.(Finish warranty does not include Oil Rubbed Bronze because it is a living finish and it is expected to patina over time)
Installation is easy, all you need is a screwdriver and a little time. The set is designed to fit standard prep doors and most installations should take just a matter of minutes.
BHMA/ANSI Grade 2 certified which indicates excellent performance across a range of residential applications. This product is built from high-quality materials to give you exceptional security.
Specifications:
Backset: 2-3/4″, 2-3/8″, Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-1/2″, 1-3/4″, 1-3/8″, 1-5/8″
Handing: Reversible
Product Weight: 1.75 lb
Latch Faceplate: Round Corner, Square Corner, Drive-In
Product Variations:
F10-ORB-COL: Passage Door Knob Set
F40-ORB-COL: Privacy Door Knob Set
F51A-ORB-COL (This Model): Keyed Entry Single Cylinder Door Knob Set
F59-ORB-COL: Keyed Entry Single Cylinder Interior Pack
F170-ORB-COL: Single Dummy Door Knob
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage Collins Collection
Specifications
| Collection | Orbit |
| Approved for Commercial Use | No |
| Series | F-Series |
| ADA | No |
| ANSI Certification | A156.2 |
| Certifications | ANSI |
| Fire Rated | Yes |
| BHMA Certification | Grade 2 |
| Thermostat | Modern |
| Concealed Screws | No |
| Cylinder | 5 Pin Schlage C |
| Cylinder Type | Single Cylinder |
| Function | Keyed Entry |
| Handshower | Left, Reversible, Right |
| Keyway | C |
| Latch Faceplate | Drive-In, Round Corner, Square Corner |
| Rosette Shape | Square |
| Handle Material | Metal |
| Knob Shape | Ball |
| Locking Mechanism | Thumbturn |
| Panic Proof | No |
| Trim Design | Collins |
| Handle Design | Orbit |
| Product Weight | 1.75 lbs. |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Edge Bore | 1" |
| Color | Satin Nickel |
| Color Tone | Nickel Tones |
