Storeroom Function: Storeroom door hardware feature an outside handle that is always locked while the inside handle is always unlocked and free turning. Entry from exterior is only possible via key.
Â
Â
Features:
Exceeds criteria for BHMA Grade 2 security certification
All metal construction for increased durability
Reversible for use with both left and right handed doors
Installs in standard prep doors with door thickness of 1-3/8″ to 1-3/4″ inches
Includes a universal latch and round corner, square corner, and drive-in faceplates
Schlage offers a Lifetime Mechanical and Finish Warranty
ADA Compliant
Specifications:
Backset: 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 7/8″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Lever Length: 4-1/2″
Projection: 2-1/4″
Cylinder: 5 Pin Schlage C
Material: Zinc
Product Weight: 2 lbs
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage Latitude Collection
Specifications
| Material | Zinc |
| Thermostat | Modern |
| Handle Material | Zinc |
| Function | Storeroom, Keyed Entry |
| Handshower | Reversible, Right, Left |
| Concealed Screws | No |
| Cylinder | 5 Pin Schlage C |
| Keyway | C |
| Latch Faceplate | Drive-In, Round Corner, Square Corner |
| Rosette Shape | Rectangle |
| Panic Proof | No |
| Lever Shape | Square, Straight |
| ADA | Yes |
| Certifications | ANSI |
| Manufacturer Warranty | Lifetime Finish |
| Approved for Commercial Use | No |
| ANSI Certification | A156.2 |
| BHMA Certification | Grade 2 |
| Fire Rated | No |
| Backset | 2-3/8", 2-3/4" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-3/8", 1-5/8", 1-3/4" |
| Edge Bore | 7/8" |
| Handle Projection | 2.25 in. |
| Handle Length | 4.5 in. |
| 28 Degree Latch | No |
| Color | Aged Bronze |
