Privacy Function: This lever is great for bathrooms or bedrooms and features a push-button lock on the interior side. The lock is released from the interior when the lever is turned and when the door is closed. The exterior side of this privacy leverset features a small pin hole that can be unlocked with a small screwdriver.
Product Features:
Push-button locking mechanism
Can be opened from outside with small screwdriver
Turning inside lever or closing door releases button
BHMA/ANSI A156.2Â Grade 1 certified
10-year limited manufacturer warranty
Fire Rated: Yes
Panic Proof: Yes
ADA approved
Specifications:
Backset: 2-3/4″, 3-3/4″, 5″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-5/8″ to 2″
Handle Length: 4.875″
Handing: Reversible
Handle Design: Rhodes
Latch Faceplate: Square corner (1-1/8″ x 2-1/4″)
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage ND-Series Collection
Specifications
| Door Thickness | 1-3/4", 1-5/8", 1-7/8", 2" |
| Backset | 2-3/4", 3-3/4" |
| Cross Bore | 2-1/8" |
| Edge Bore | 1" |
| Handle Length | 4.875 in. |
| Approved for Commercial Use | Yes |
| Series | ND-Series |
| Manufacturer Warranty | 10 Year Limited |
| ANSI Certification | A156.2 |
| Certifications | ANSI, UL |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
| Thermostat | Modern |
| Handle Material | Metal |
| Function | Privacy |
| Style | Commercial |
| Latch Faceplate | Square Corner |
| Concealed Screws | Yes |
| Handshower | Left, Reversible, Right |
| Panic Proof | Yes |
| Lever Shape | Straight |
| Handle Design | Rhodes |
| Mortise | No |
| Color | Matte Black, Oil Rubbed Bronze, Polished Brass, Polished Chrome, Satin Brass, Satin Bronze, Satin Chrome, Satin Nickel |
| Color Tone | Blacks, Brass Tones, Bronze Tones, Nickel Tones, Silver Tones |
