Privacy Function: This lever is great for bathrooms or bedrooms and features a push-button lock on the interior side. The lock is released from the interior when the lever is turned and when the door is closed. The exterior side of this privacy leverset features a small pin hole that can be unlocked with a small screwdriver.
Product Features:
Push-button locking mechanism
Can be opened from outside with small screwdriver
Turning inside lever or closing door releases button
BHMA/ANSI A156.2Â Grade 1 certified
Fire Rated: Yes
Panic Proof: Yes
ADA approved
Specifications:
Backset: 2-3/4″, 3-3/4″, 5″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-5/8″ to 2-1/8″
Handle Length: 4.9375″
Handing: Reversible
Handle Design: Sparta
Latch Faceplate: Square corner (1-1/8″ x 2-1/4″)
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage ND-Series Collection
Specifications
| Thermostat | Transitional |
| Handle Material | Metal |
| Handshower | Reversible |
| Latch Faceplate | Square Corner |
| Style | Commercial |
| Concealed Screws | Yes |
| Function | Privacy |
| Rosette Shape | Round |
| Lever Shape | Straight |
| Interconnected | No |
| Panic Proof | Yes |
| Handle Design | Sparta |
| Mortise | No |
| Approved for Commercial Use | Yes |
| Collection | Sparta |
| ADA | Yes |
| Series | ND-Series |
| Certifications | ANSI, UL |
| ANSI Certification | A156.2 |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
| Edge Bore | 1" |
| Backset | 2-3/4", 3-3/4", 5", 2-3/8" |
| Door Thickness | 1-3/4", 1-5/8", 1-7/8", 2" |
| Handle Length | 4.9375 in. |
| Color | Oil Rubbed Bronze |
| Color Tone | Bronze Tones |
