Keyed Corridor Lock: The corridor function provides push-button locking from the inside and by a key on the outside. When locked from the inside by the push-button turning the inside lever or closing the door will release the button. When the lever is locked by a key it can only be unlocked by a key. The inside lever is always unlocked providing panic proof exiting.
Features:
Cylinder options are provided for Schlage C keyway
Meets ANSI/BHMA Certification A156.2/Grade 1
All metal construction for durability
Left or right handing allows versatile application
This product is compliant with ADA standards
Panic Proof: Yes
Fire Rated: Yes
This lever and trim have concealed screws
Product Technologies:
Installation is easy, all you need is a screwdriver and a little time. The set is designed to fit standard prep doors and most installations should take less than an hour.
These levers are field reversible allowing this leverset to be used for both right and left handed applications with ease and eliminating any chance of getting a wrong handed product.
Specifications:
Lever Length: 4-15/16″
Handing: Reversible (left or right)
Backset:Â 2-3/4″, 2-3/8″, 3-3/4″, 5″
Door Thickness:Â 1-3/4″, 1-5/8″, 1-7/8″, 2″, 2-1/8″
Handle Design: Tubular
Cylinder: Cylinder: Schlage C Keyway 6-Pin
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage ND-Series Collection
Specifications
| Thermostat | Modern |
| Handle Material | Metal |
| Handshower | Left, Reversible |
| Latch Faceplate | Square Corner |
| Style | Commercial |
| Concealed Screws | Yes |
| Cylinder | 6 Pin |
| Cylinder Type | Single Cylinder |
| Function | Keyed Entry, Corridor |
| Keyway | C |
| Rosette Shape | Round |
| Lever Shape | Round, Straight |
| Panic Proof | Yes |
| Interconnected | No |
| Handle Design | Tubular |
| Mortise | No |
| Manufacturer Warranty | 10 Year Limited |
| Approved for Commercial Use | Yes |
| Collection | Tubular |
| Series | ND-Series |
| Certifications | ANSI |
| ANSI Certification | A156.2 |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
| Edge Bore | 1" |
| Backset | 2-3/4", 3-3/4", 5" |
| Door Thickness | 1-3/4", 1-5/8", 1-7/8", 2" |
| Handle Length | 4.9375 in. |
| Interchangeable Core | No |
| Color | Oil Rubbed Bronze |
| Color Tone | Bronze Tones |
