Product Features:
Push-button locking.
Can be unlocked from outside with small circular tool.
Turning inside lever releases button.
Closing the door does not release button (restoring).
Handing is reversible for either left or right handed applications
Specifications:
Backset: Adjustable for either 2-3/8″ or 2-3/4″
Crossbore: 2-1/8″
Edgebore: 7/8″
Door Thickness: 1-1/2″, 1-3/4″, 1-3/8″, 1-5/8″, 1-7/8″
Latch: 1″ x 2 1/4″, Square corner faceplate, 7/8″ housing diameter, 1/2″ throw
Strike: 1 1/8″ x 2 3/4″, Square corner, T-strike, box
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage S-Series Collection
Specifications
Characteristics and Features
| Thermostat | Modern |
| Style | Commercial |
| Latch Faceplate | Round Corner, Square Corner |
| Handshower | Left, Reversible, Right |
| Function | Privacy |
| Handle Material | Metal |
| Concealed Screws | Yes |
| Panic Proof | Yes |
| Rosette Shape | Round |
| Lever Shape | Straight |
| Handle Design | Saturn |
| Mortise | No |
Warranty and Product Information
| Approved for Commercial Use | Yes |
| Collection | Saturn |
| Manufacturer Warranty | 3 Year Limited |
| ADA | Yes |
| Series | S-Series |
| Certifications | ANSI, UL |
| ANSI Certification | A156.2 |
| Fire Rated | Yes |
| BHMA Certification | Grade 2 |
Dimensions and Measurements
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8", 1-7/8" |
| Backset | 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Handle Length | 4.25 in. |
| Color | Antique Brass |
| Color Tone | Brass Tones |
