S-Series Jupiter Commercial Grade 2 Light Duty Storeroom Lever Set Less Interchangeable Core (Core Options Provided)
This S80RD-JUP Jupiter storeroom lever set adds charm to a traditional scroll design. This lever set has a fixed outside lever with entrance by a key only. The inside lever is always unlocked for immediate exit.
Schlage S-Series levers are engineered for long life and optimum durability. Easy to install, service and maintain, an S-Series lever can help you keep people and property secure.
Features:
Jupiter Storeroom Lever Set
ADA Compliant
Adjustable Backset 2-3/8″ or 2-3/4″
Door Thickness 1-3/8″ to 2″
1″ x 2-1/4″ Square Corner Faceplate Standard
1-1/8″ x 2-3/4″ Square Corner T Strike with Dist Box Standard
2-1/8″ Cross Bore
7/8″ Edge Bore
Meets or Exceeds A156.2 Series 4000, Grade 2 Strength and Operational Requirements
Specifications:
Lever Length: 4-1/4″
Lever Projection: 2-1/2″
Lever Rose Diameter: 2-9/16″
For over 90 years, Schlage has been making homes more stylish and secure with the best door locks and door hardware. Today the Schlage family of products also includes the very best in electronic locks, keyless door locks, and home security. Let Schlage’s hardware and security solutions protect and enhance the things that matter most to you.
Additional Schlage Links
View the Manufacturer Warranty
Browse all Schlage Products
Schlage S-Series Collection
Specifications
| Thermostat | Modern |
| Material | Zinc |
| Handle Material | Metal |
| Handshower | Right, Left, Reversible |
| Latch Faceplate | Round Corner, Square Corner |
| Style | Commercial |
| Concealed Screws | Yes |
| Cylinder | 6 Pin Schlage C |
| Cylinder Type | Single Cylinder |
| Function | Keyed Entry, Storeroom |
| Keyway | C123 |
| Rosette Shape | Round |
| Lever Shape | Straight |
| Panic Proof | Yes |
| Interconnected | No |
| Handle Design | Jupiter |
| Interchangeable Core Type | Full Size |
| Mortise | No |
| ADA | Yes |
| Manufacturer Warranty | 3 Year Limited |
| Approved for Commercial Use | Yes |
| Collection | Jupiter |
| Series | S-Series |
| Certifications | ANSI, UL |
| ANSI Certification | A156.2 |
| BHMA Certification | Grade 2 |
| Fire Rated | Yes |
| Edge Bore | 7/8" |
| Backset | 5", 2-3/4", 2-3/8" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-3/8", 1-5/8", 1-7/8", 1-3/4", 2" |
| Handle Projection | 2.5 in. |
| Trim Height | 2.5625 in. |
| Trim Width | 2.5625 in. |
| Handle Length | 4.25 in. |
| Interchangeable Core | Yes |
| Color | Satin Chrome |
| Color Tone | Silver Tones |
