Sloan Battery Powered, Sensor Activated Retrofit Unit for Exposed Closet and Urinal Flushometers

Retrofit Kit – Battery Powered, Sensor Activated Retrofit Unit for Exposed Closet and Urinal Flushometers.

Battery Powered, Sensor Activated, Exposed, OPTIMA(R) SMOOTH(tm) Unit for Closet and Urinal Flushometer Conversions

Side Mount Operator for Water Closets (Toilets) and Urinals

Features:

Sensor operated
Battery powered retrofit kit
Easily converts manual flushometer into water saving electronics
Side-mount-operator-over-the-handle retrofit kit for water closets and urinals
ADA Compliant OPTIMA(R) SMOOTH(tm) Battery Powered Infrared Sensor for automatic “Hands-free” operation
Sensor with Automatic Range Adjustment
Chrome Plated Metal Sensor Housing
Mechanical Manual Override Flush Handle
Four (4) Size C Batteries included
“Low Battery” Flashing LED
“User in View” Flashing LED
Sentinel Flush Mode
Vandal Resistant 1/8″ Ball-Type Hex Key included
25 to 80 psi Operating Range
Infrared Sensing with Automatic Adjustment
Mechanical Manual Override
Four (4) replaceable Size C Batteries

Easy Installation:
Sloan SMOOTH(tm) works out of the box and installs in minutes. Simply slide the unit over the Flushometer handle and tighten the clamp.
Automatic:
Sloan SMOOTH(tm) equipped Flushometers provide the ultimate in sanitary protection and automatic operation. There is no need for AC hookups or wall alterations. The Flushometer operates by means of a battery powered infrared sensor. Once the user enters the sensor’s effective range and then steps away, the SMOOTH(tm) Unit initiates the flushing cycle to flush the fixture. State-of-the-art Technology enables activation of a manual override without “double flushing” occurring as the user departs (locks out sensor for approximately 10 seconds). 72 hour Sentinel Flush keeps fixture fresh during periods of nonuse.
Hygienic:
The Sloan SMOOTH(tm) Flushometer retrofit kit is the next advancement in hygiene. It uses sensor technology to transform manual installations into electronic, hands-free operation. User makes no physical contact with the Flushometer surface except to initiate the Override Handle when required. Helps control the spread of infectious diseases.
Economical:
Automatic operation provides water usage savings over other flushing devices. Reduces maintenance and operation costs. Installation and battery replacement does not require turning off water to the valve.
Warranty:
3 year (limited)

Electrical Specifications:

Control Circuit:
6 VDC Input
8 Second Arming Delay
72 Hour Sentinel Flush
OPTIMA Sensor Range:
Normal Range (recommended for Water Closets) with 2 – 3 second flush delay:
26″ – 32″ (660 mm – 813 mm)
Normal Range (recommended for Water Closets) with 1 – 2 second flush delay:
26″ – 32″ (660 mm – 813 mm)
Reduced Range (recommended for Urinals) with 1 – 2 second flush delay:
20″ – 26″ (508 mm – 660 mm)
OPTIMA Sensor Type:
Active Infrared with Automatic
Adjustment
Battery Type:
(4) Size C Alkaline
Battery Life:
2 Years @ 4,000
Flushes/Month
Indicator Lights:
User in View/Low Battery
Operating Pressure:
25-80 psi (172-552 kPa)
