Concealed, (0.5 gpf/1.9 Lpf), Prison Urinal Flushometer, for stainless steel 3/4″ back inlet urinals.
Dual Filtered By-Pass
Diaphragm, Handle Packing, Stop Seat and Vacuum Breaker to be molded from PERMEX(tm) rubber compound for Chloramine resistance
Metal Non-Hold-Open Push Button with a Triple Seal Handle Packing
3/4″ I.P.S. Wheel Handle Bak-Chek(tm) Angle Stop
Adjustable Tailpiece
High Back Pressure Vacuum Breaker
Elbow Flush Connection
Coupling for 3/4″ NPT Back Inlet Urinals (for connection in the pipe chase – flush connection through the wall not provided by Sloan)
Sweat Solder Adapter
Exposed parts Chrome Plated
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance to the applicable sections of ASSE 1037, ANSI/ASME 112.19.6, and Military Specification V-29193.
CEC flow rate compliant when paired with non-wall mounted urinals. Non-compliant when paired with wall mounted urinals – CEC regulation requires 0.125 GPF
Additional Sloan Links
View the Manufacturer Warranty
Browse all Sloan Products
Sloan Royal Collection
Specifications
| Approved for Commercial Use | Yes |
| CA Drought Compliant | No |
| Eco Friendly | No |
| TX Drought Compliant | Yes |
| Insulation Type | Urinal |
| Water Efficient | Yes |
| Control Type | Manual |
| Spud Placement | Rear |
| Gallons Per Flush | 0.5 |
| Color | Chrome |
| Color Tone | Silver Tones |
