Features:
Designed to support up to 75 pounds of weight
Mounts to the side of the drawer
Provides easy access to the drawer with full extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a 1 year limited manufacturer warranty
Product Technologies:
Detent: Also known as anti-rebound, slide detent acts like a brake; ensuring your drawers do not roll back open when closed with too much force.
Specifications:
Recommended Drawer Length: 20-1/2″
Slide Length: 20″
Extension Type: Full Extension
Slide Type: Ball Bearing
Weight Capacity: 75 lbs
Material: Stainless Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Product Variations:
ESR3813-8: 8 Inch Drawer Slide
ESR3813-10: 10 Inch Drawer Slide
ESR3813-12: 12 Inch Drawer Slide
ESR3813-14: 14 Inch Drawer Slide
ESR3813-16: 16 Inch Drawer Slide
ESR3813-18: 18 Inch Drawer Slide
ESR3813-20 (This Model): 20 Inch Drawer Slide
ESR3813-22: 22 Inch Drawer Slide
Additional Sugatsune Links
Browse all Sugatsune Products
Sugatsune ESR3 Collection
Specifications
| Length | 20 in. |
| Nominal Length | 20 in. |
| Quantity | 2 |
| Extension | 20 in. |
| Max Capacity (Pounds) | 75 lbs. |
| Drainboard Length | 20.5 in. |
| Minimum Cabinet Depth | 19.685 in. |
| Manufacturer Warranty | 1 Year Limited |
| Approved for Commercial Use | No, Yes |
| Country Of Origin | China |
| Series | ESR3 |
| Insulation Type | Side Mount |
| Material | Stainless Steel |
| Mounting Type | Side Mount |
| Adjustable | No |
| Extension Type | Full Extension |
| Soft Close | No |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Push to Open | No |
| Self Closing | No |
| Detent | Yes |
| Disconnect Style | Lever |
| Slide Type | Ball Bearing |
| Installation Hardware Included | No |
| Color | Stainless Steel |
