Features:
Large 2.3 Cu. Ft. oven made from durable porcelain enamel
4 traditional gas burners provide even and solid heating
Simple knob controls make cooking easy
Broiler is located in a lower drop-down compartment
Covered under a 1 year limited manufacturer warranty
Specifications:
Total Capacity: 2.3 Cu. Ft.
Back Left Burner BTU: 9500
Back Right Burner BTU: 5000
Front Left Burner BTU: 9500
Front Right Burner BTU: 12000
Convection: No
Sabbath Mode: No
Self Cleaning: No
Depth: 24-1/4″
Height: 42″
Width: 19-1/2″
Additional Summit Links
View the Manufacturer Warranty
Browse all Summit Products
Specifications
Warranty and Product Information
| Approved for Commercial Use | No |
| Country Of Origin | Mexico |
| Manufacturer Warranty | 1 Year Limited |
| Certifications | UL |
| ADA | Yes |
| Product Variation | Range with Single Oven |
Dimensions and Measurements
| Height | 42 in. |
| Width | 19.5 in. |
| Depth | 24.25 in. |
| Nominal Height | 42 in. |
| Nominal Width | 20 in. |
| Nominal Depth | 25 in. |
| Oven Capacity | 2.3 cu. ft. |
| Total Capacity | 2.3 cu. ft. |
| Cup Depth | 25 in. |
| Cutout Height | 44 in. |
| Cutout Width | 20 in. |
Characteristics and Features
| Insulation Type | Free Standing |
| Material | Steel |
| Burner Style | Sealed |
| Control Type | Knob |
| Configuration | No |
| Door Features | Viewing Window |
| Drain Type | Broiler Drawer |
| LP Conversion | Yes |
| Number of Bulbs | 4 |
| Sabbath Mode | No |
| Self Closing | No |
| Warm Function | No |
| Smart Home | No |
| Continuous Grates | Yes |
| Number of Racks | 2 |
Electrical and Operational Information
| Fuel Type | Gas |
| Voltage | 115 |
| Frequency | 60 Hertz |
| Ignition Type | Electronic |
| Total BTUs | 36000 |
| Back Left Burner BTU | 9500 |
| Back Right Burner BTU | 5000 |
| Front Left Burner BTU | 9500 |
| Front Right Burner BTU | 12000 |
| Gas Type | Natural Gas |
Included Components
| Clock | No |
| Rotisserie | No |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
