Features:
24″ fit is ideal for smaller homes
Smooth ceramic glass cooking surface ensures easy cleanup and safer cooking
Slide-in style look lets you better integrate the range with your own backsplash design
Easier monitoring of your cooking with an oven window and on/off light
Save even more space by storing your pots and pans in this pull-out storage drawer compartment
Unit ships with low stainless steel backguard but can be easily converted to a traditional slide-in style for a more integrated look
Broiler is located inside the oven, making it easier to use
Control panel is conveniently located to prevent users from reaching over hot cooktop surface for adjustments
Surface features two 8″ and two 6″ elements to accommodate a range of sizes and cooking needs
To prevent accidents, knobs require a small amount of force when turning
Covered under a 1 year parts and labor manufacturer warranty
Specifications:
Total Capacity: 2.9 Cu. Ft.
Back Left Burner Watts: 2000
Back Right Burner Watts: 1500
Front Left Burner Watts: 2000
Front Right Burner Watts: 1500
Broil Element: Yes
Convection: No
Sabbath Mode: No
Self Cleaning: No
Depth: 24-1/4″
Height: 36-1/2″
Width: 23-3/4″
Additional Summit Links
View the Manufacturer Warranty
Browse all Summit Products
Specifications
| Thermostat | Modern |
| Insulation Type | Free Standing |
| Door Features | Viewing Window |
| Burner Style | Radiant |
| Continuous Grates | No |
| Control Type | Knob |
| Downdraft Ventilated | No |
| Hot Surface Indicator Lights | Yes |
| Number of Bulbs | 4 |
| Sabbath Mode | No |
| Broil Element | Yes |
| Configuration | No |
| Self Closing | No |
| Warm Function | No |
| Drain Type | Storage Drawer |
| ADA | Yes |
| Approved for Commercial Use | No |
| Manufacturer Warranty | 1 Year Parts and Labor |
| Country Of Origin | Mexico |
| Certifications | UL |
| Energy Star | No |
| Product Variation | Range with Single Oven |
| Height | 36.5 in. |
| Depth | 24.25 in. |
| Width | 23.75 in. |
| Product Weight | 140 lbs. |
| Nominal Depth | 24 in. |
| Nominal Height | 37 in. |
| Nominal Width | 24 in. |
| Cup Depth | 24.25 in. |
| Cutout Height | 36.5 in. |
| Cutout Width | 24 in. |
| Total Capacity | 2.9 cu. ft. |
| Oven Capacity | 2.9 cu. ft. |
| Height to Top of Cook Top | 38.38 in. |
| Bulb Included | Yes |
| Light Included | Yes |
| Griddle | No |
| Voltage | 220 |
| Wattage | 7000 |
| Amperage | 40 |
| Back Left Burner Watts | 2000 |
| Back Right Burner Watts | 1500 |
| Frequency | 60 Hertz |
| Front Left Burner Watts | 2000 |
| Front Right Burner Watts | 1500 |
| Fuel Type | Electric |
| Auto Shut Off | No |
| Color | Black |
| Color Tone | Blacks |
