Features:
This 2.9 cubic foot range is the perfect complement to a smaller kitchen space
Includes a high-powered 12,000 BTU burner for powerful heating, one (1) 5,000 BTU burner ideal for simmering, and two (2) standard 9,500 BTU burners to meet other cooking needs
The boiler is located in a lower drop-down compartment and comes with a two-piece broiler an with lid
Push-to-turn knobs prevent accidents and come with indicator lights for each burner for added safety
Safety features include indicator lights for the burners and the oven ensuring that you always know what is in use
Unit is set for natural gas but can be converted aftermarket with the included LP kit
Manufacturer warranty includes 1 year parts and labor
Specifications:
Total Capacity: 2.9 Cu. Ft.
Broil Element: Yes
Back Left Burner BTU: 9500
Back Right Burner BTU: 9500
Front Left Burner BTU: 5000
Front Right Burner BTU: 12000
Cutout Depth: 25″
Cutout Width: 24″
Depth: 23-1/2″
Height: 42″
Width: 23-1/2″
Amperage: 5A
Voltage: 115V
Additional Summit Links
View the Manufacturer Warranty
Browse all Summit Products
Specifications
| Depth | 23.5 in. |
| Width | 23.5 in. |
| Product Weight | 150 lbs. |
| Cup Depth | 25 in. |
| Cutout Height | 43 in. |
| Cutout Width | 24 in. |
| Height | 42 in. |
| Nominal Depth | 24 in. |
| Nominal Height | 42 in. |
| Nominal Width | 24 in. |
| Oven Capacity | 2.9 cu. ft. |
| Total Capacity | 2.9 cu. ft. |
| Depth with Door Open | 43.25 in. |
| ADA | Yes |
| Approved for Commercial Use | No |
| Certifications | UL |
| Country Of Origin | Mexico |
| Manufacturer Warranty | 1 Year Parts and Labor |
| Energy Star | No |
| Outdoor Approved | No |
| Product Variation | Range with Single Oven |
| Baking Element | Yes |
| Interior Light | Yes |
| Light Included | Yes |
| Meat Thermometer | No |
| Clock | No |
| Broil Element | Yes |
| Burner Style | Sealed |
| Continuous Grates | Yes |
| Control Type | Knob |
| Configuration | No |
| Door Features | Viewing Window |
| Drain Type | Broiler Drawer |
| Insulation Type | Free Standing |
| LP Conversion | Yes |
| Number of Bulbs | 4 |
| Number of Racks | 2 |
| Sabbath Mode | No |
| Self Closing | No |
| Smart Home | No |
| Dispenser Type | Analog |
| Amperage | 5 |
| Auto Shut Off | No |
| Back Left Burner BTU | 9500 |
| Back Right Burner BTU | 9500 |
| Frequency | 60 Hertz |
| Front Left Burner BTU | 5000 |
| Front Right Burner BTU | 12000 |
| Fuel Type | Gas |
| Gas Type | Natural Gas |
| Ignition Type | Electronic |
| Induction | No |
| Power Burner | Yes |
| Total BTUs | 36000 |
| Voltage | 115 |
| Color | White |
