Dummy Set: Dummy handlesets have no latch or locking mechanism but give the appearance of a single cylinder handleset. Typically, dummy handlesets are used as a pull on the inactive side of a double door entry. Pair this with a single cylinder version to make a complete set for a full double door solution. This dummy set comes with both the exterior handleset and the interior.
Features:
Tested to exceed ANSI/BHMA Grade 3 security requirements
Constructed of high quality materials for durability and dependability
Installs easily with all necessary mounting hardware included
Covered by Weslock’s 25 year mechanical, and 5 year finish manufacturer warranty
Specifications:
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Material: Zinc
Mounting Center to Center: 5-1/2″
Grip Center to Center: 8-7/16″
Overall Height: 17-3/4″
Trim Height: 17-3/4″
Trim Width: 2-5/8″
Interior Handle Length: 4-1/2″
Interior Handle Projection: 2-3/4″
Additional Weslock Links
View the Manufacturer Warranty
Browse all Weslock Products
Weslock Mercy Collection
Specifications
| Material | Zinc |
| Handle Style | Grip |
| Thermostat | Modern |
| Handshower | Left, Reversible, Right |
| Handle Material | Metal |
| Concealed Screws | No |
| Function | Dummy Set |
| Adjustable Throughbolt | No |
| Handle Design | Mercy |
| Interior Handle Style | Lever |
| Mounting | Sectional |
| ADA | No |
| Approved for Commercial Use | No |
| Collection | Premiere Essentials |
| Manufacturer Warranty | 25 Year Mechanical, 5 Year Finish |
| Certifications | ANSI |
| Country Of Origin | China |
| ANSI Certification | A156.2 |
| Series | Mercy |
| BHMA Certification | Grade 3 |
| Product Weight | 3.1 lbs. |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Center to Center | 5.5 in. |
| Interior Handle Length | 4.5 in. |
| Interior Handle Projection | 2.75 in. |
| Trim Height | 17.75 in. |
| Trim Width | 2.625 in. |
| Overflow Height | 17.75 in. |
| Grip Center to Center | 8.4375 in. |
| Interior Trim Height | 2.625 in. |
| Interior Trim Width | 2.625 in. |
| Interior Included | Yes |
| Color | Oil Rubbed Bronze |
| Color Tone | Bronze Tones |
