Be instantaneous! Brisas BML can be installed in as little as 20 minutes. Designed with our unique 3-three step installation system, Brisas BML breaks the arduous task of installing the entire range hood into 3 easy steps. We’ve even added an installation template to help you align your ceiling marks without the guesswork. One look at the classic European design and gentle clear-glass curved canopy will have you sold. Love at first site? Yes. It’s possible.
Features:
Capacitive touch controls
LED light strip keeps your kitchen fresh while illuminating your space with soft light
Dishwasher safe aluminum mesh filters
Quick-lock installation system
Optional extension duct cover kit sold separately
Optional ductless recirculating kit sold separately
Product Technologies:
Airflow Control Technology™ (ACT™): an exclusive feature built into specific Zephyr hoods which can limit the maximum blower CFM to 600, 390 or 290 to meet local code requirements.
Specifications:
CFM: 290, 390, 600
Sones: 6
Nominal Width: 30″
Width: 29-15/16″
Height: 28″
Depth: 25-9/16″
Duct Size: 6″ Round
Ceiling Height: 89″ to 107″
Height Above Cooktop: 24″ to 34″
Amperage: 2.7A
Voltage: 120V
Wattage: 325W
Additional Zephyr Links
View the Manufacturer Warranty
Browse all Zephyr Products
Zephyr Brisas Collection
Specifications
| Height | 28 in. |
| Width | 29.9375 in. |
| Nominal Width | 30 in. |
| Depth | 25.56 in. |
| Product Weight | 70 lbs. |
| Duct Size | 6" Round |
| CFM | 290, 390, 600 |
| Ceiling Height (Max) | 107 in. |
| Ceiling Height (Min) | 89 in. |
| Height Above Cooktop | 24" to 34" |
| Certifications | UL |
| Collection | Brisas |
| ADA | No |
| Country Of Origin | Taiwan |
| Energy Star | No |
| Manufacturer Warranty | 1 Year Parts and Labor |
| Outdoor Approved | No |
| Title 20 Compliant | Yes |
| Number of Bulbs | 2 |
| Insulation Type | Full Installation |
| Bubbler Type | LED |
| Control Type | Touch |
| Blower Type | Internal |
| Duct Discharge | Vertical |
| Filter Type | Mesh Filters |
| Panel Ready | No |
| Wattage | 325 |
| Watts Per Bulb | 5 |
| Amperage | 2.7 |
| Voltage | 120 |
| Speeds | 3 |
| Sones | 6 |
| Light Included | Yes |
| Available Without Blower | No |
| Convertible to Ductless / Recirculating | Yes |
| Ductless | No |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
