Exceptional style, plus the power and performance you’d expect from Zephyr. Featuring white or black glass with matte finish, our Perimeter Aspiration System, easy Capacitive Touch Controls and a recirculating option, the Apex Wall is a hood for today, tomorrow, and beyond. Also includes optional duct cover and remote control.
Features:
Keeps your kitchen free of cooking fumes and odors
Multiple blower options are available to fit your application
Capacitive touch controls utilize the same touch technology as your smart phone for a more integrated user interface
Tri-Level lighting illuminates cooking area
Wireless remote control places the hood’s operations at your fingertips from anywhere in the kitchen (remote not included)
Extension duct cover kit to accommodate ceiling heights up to 12′ (see spec sheets for more details)
ADA compliant with optional remote
Covered under a 1 year labor and 2 year parts warranty
Product Technologies:
Optional Ductless Recirculating Kit: Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen
Specifications:
Nominal Width: 36″
Width: 35-3/8″
Height: 19-3/4″
Depth: 19-13/16″
Duct Size: 10″ Round, 6″ Round, 8″ Round
Ceiling Height: 96″ – 132″
ADA Approved: Yes (with optional remote)
Voltage: 120V
Additional Zephyr Links
View the Manufacturer Warranty
Browse all Zephyr Products
Zephyr Apex Collection
Specifications
| Depth | 19.81 in. |
| Height | 19.75 in. |
| Product Weight | 55 lbs. |
| Width | 35.375 in. |
| Nominal Width | 36 in. |
| Ceiling Height (Min) | 96 in. |
| Duct Size | 10" Round, 6" Round, 8" Round |
| Height Above Cooktop | 24" to 36" |
| Ceiling Height (Max) | 132 in. |
| Light Included | Yes |
| Bulb Included | Yes |
| Available Without Blower | Yes |
| Convertible to Ductless / Recirculating | Yes |
| Ductless | Yes |
| Includes Remote | No |
| Material | Metal |
| Bubbler Type | LED |
| Insulation Type | Shell Only |
| Number of Bulbs | 2 |
| Smart Home | No |
| Panel Ready | No |
| Control Type | Touch |
| Blower Type | External, In-Line, Internal |
| Duct Discharge | Horizontal, Vertical |
| Filter Type | Mesh Filters |
| Collection | Designer Collection |
| Approved for Commercial Use | No |
| Country Of Origin | Italy |
| Manufacturer Warranty | 1 Year Labor, 2 Year Parts |
| Outdoor Approved | No |
| ADA | Yes |
| Title 24 | Yes |
| Title 20 Compliant | Yes |
| Energy Star | No |
| Voltage | 120 |
| Wattage | 770 |
| Watts Per Bulb | 5 |
| Amperage | 6.42 |
| Speeds | 3 |
| Color | Matte Black, Matte White |
| Color Tone | Blacks, Whites |
