The delicate curve of a glass canopy arching over your cooktop will add an elegance to your everyday cooking experience. Featuring Zephyr’s trend-setting black stainless steel, the Ravenna combines 21st century know-how with timeless beauty. Featuring clear and smoke-gray glass canopy options, Airflow Control Technology (ACT™), ICON Touch® controls, LumiLight LED lighting, and a powerful — yet quiet — 600-CFM blower. Now available with an optional ADA-compliant remote control.
Features:
Blower outputs up to 600 CFM to keep your kitchen free of cooking fumes and odors
Mesh filters effectively trap and filter out unwanted smoke, odors, and grease
Hood can be converted to ductless ventilation for improved efficiency and flexible installation options
Touch controls allow you to easily set the power level of your range hood
5 available speeds provide just the right amount of ventilation
Airflow Control Technology™ (ACT™)
Icon touch® controls
Lumilight LED dual-level lighting
Curved glass canopy
Optional ductless recirculating kit
Optional extension duct cover kit
Covered under 1 year labor and 3 year parts manufacturer warranties
Product Technologies:
Airflow Control Technology™ (ACT™): An exclusive feature built into specific Zephyr hoods which can limit the maximum blower CFM to 590 390 or 290 to meet local code requirements.
Convertible Range Hood: Convertible range hoods can function either as a ventilated (ducted) or recirculating unit. The primary benefit being that it allows for the broadest compatibility across multiple kitchen environments. A convertible unit can be made into recirculating typically through the purchase of a recirculating kit. Convertible units don’t compromise their efficiency or functionality between ducted or re-circulating configurations, leaving the choice entirely dependent on what’s the most convenient for the end user.
Specifications:
CFM: 290, 390, 600
Sones: 1, 6
Nominal Width: 36″
Width: 35-1/2″
Depth: 19-3/4″
Duct Size: 6″ Round
Ceiling Height: 96″ – 108″
Height Above Cooktop: 26″ to 34″
Amperage: 4A
Voltage: 120V
Wattage: 480W
Additional Zephyr Links
View the Manufacturer Warranty
Browse all Zephyr Products
Zephyr Ravenna Collection
Specifications
| Bubbler Type | LED |
| Insulation Type | Full Installation |
| Material | Stainless Steel |
| Smart Home | No |
| Panel Ready | No |
| Control Type | Touch |
| Filter Type | Mesh Filters |
| Blower Type | Internal |
| Duct Discharge | Vertical |
| Voltage | 120 |
| Wattage | 480 |
| Amperage | 4 |
| Speeds | 5 |
| Sones | 1, 6 |
| Energy Star | No |
| Country Of Origin | Taiwan |
| Manufacturer Warranty | 1 Year Labor, 3 Year Parts |
| Outdoor Approved | No |
| Title 20 Compliant | No |
| Width | 35.5 in. |
| Depth | 19.75 in. |
| Nominal Width | 36 in. |
| Product Weight | 53 lbs. |
| Ceiling Height (Max) | 108 in. |
| Ceiling Height (Min) | 96 in. |
| Duct Size | 6" Round |
| Height Above Cooktop | 24" to 34" |
| CFM | 290, 390, 600 |
| Height Above Cooktop (Min) | 24 in. |
| Height Above Cooktop (Max) | 34 in. |
| Light Included | Yes |
| Available Without Blower | No |
| Convertible to Ductless / Recirculating | Yes |
| Ductless | No |
| Includes Remote | No |
| Color | Black Stainless Steel |
| Color Tone | Stainless Steel |
