1/2 HP Manual Submersible Sewage and Effluent Pump
Zoeller 267-0002 Features:
Non-clogging vortex impeller design
Float operated, submersible (NEMA 6) 2-pole switch
Durable cast iron construction
Cast iron base
Engineered plastic impeller with metal insert
Not effected by materials normally found in drainage and sewage sumps
Stainless steel screws, bolts, handle, guard, arm, and seal assembly
180″ UL listed 3-wire neoprene cord and plug
Oil-filled, hermetically sealed motor with automatic reset thermal overload protection
Oil lubricated bearings
Carbon and ceramic shaft seal
Passes 2″ spherical solids
Corrosion resistant powder coated epoxy finish
Zoeller 267-0002 Specifications:
Height: 14.28″
Length: 11.21875
Width: 13.0625″
Category: Sewage Pumps
Connection Size: 2″ NPT
Flow Rate: 128 gpm
1/2 HP motor
Maximum Head Height: 21.5′
Voltage: 115V
Weight: 52 lbs.
Additional Zoeller Links
View the Manufacturer Warranty
Specifications
| Height | 14.28 in. |
| Width | 13.06 in. |
| Product Weight | 52 lbs. |
| Length | 11.219 in. |
| Water Connection | 2" |
| Flow Rate (GPM) | 128 |
| Maximum Head Height | 21.5 in. |
| Voltage | 115 |
| Horsepower | .5 |
| Electrical Phases | 1 |
| Maximum Fluid Temperature | 130 °F |
| Motor RPM | 1750 |
| Water Connection Type | NPT |
| Impeller Material | Plastic |
| Material Casing | Iron |
| Material Housing | Iron |
| Certifications | UL |
