3000 Series Light Duty Commercial Door Closer
Delaney commercial door closers bring you both safety and function in a single package. With several options to choose from, and a line of accessories to customize your equipment, Delaney makes it simple to obtain the perfect hardware for any job. Whether dealing with heavy traffic or light, these surface-mounted door closers are sure to impress.
Delaney’s 3000 Series light duty commercial door closer is the perfect choice for those low traffic areas. Available in both Aluminum and Duro Bronze finishes.
Features:
ANSI 156.4 Grade 1
Theme: Functional
Heavy Duty Rack and Pinion with Heat Treated High Tension Piston
High Lubricity Hydraulic Fluid to Ensure Smooth Operation
Standard Arm and Parallel Bracket Included
Standard Arm Installation Allows Door to Swing 180 Degrees
Additional Delaney Links
Browse all Delaney Products
Delaney 3000 Collection
Specifications
| Product Weight | 5.3 lbs. |
| Height | 1.8125 in. |
| Projection | 2.8125 in. |
| Closer Body Length | 8.875 in. |
| Closer Size | 3 |
| Horizontal Mounting Holes | 8.1875 in. |
| Max Door Opening | 180 Degrees |
| Max Door Weight | 143 lbs. |
| Max Door Width | 42 in. |
| Vertical Mounting Holes | 2.375 in. |
| Manufacturer Warranty | 5 Year |
| Collection | 3000 |
| Series | 3000 |
| Approved for Commercial Use | Yes |
| ADA | No |
| Certifications | ANSI, UL10C, UL |
| ANSI Certification | A156.4 |
| Fire Rated | Yes |
| BHMA Certification | Grade 2 |
| Usage Level | Light Duty |
| Material | Cast Iron |
| Handshower | Reversible, Left, Right |
| Barrier Free | No |
| Arm Type | Standard |
| Adjustable Backcheck | No |
| Adjustable Spring | No |
| Delay Action | No |
| Hold Open | No |
| Mounting | Tri-Pack, Regular, Parallel, Top Jamb |
| Operation Mode | Hydraulic |
| Shell Material | Cast Iron |
| Adjustable Closing Speed | Yes |
| Adjustable Latching Speed | Yes |
| Cushion Stop | No |
| Color | Duro Bronze |
| Color Tone | Bronze Tones |
