Product Features:
Quiet action, Teck exposed diaphragm flush valve
Vandal resistant cover screw
Metal (non hold open) ADA Compliant oscillating handle
Vacuum breaker
Renewable seat
Chloramine resistant diaphragm attached to guide with forged metal retainer
Spud flange and concealed spud nut
For water closets with 1-1/2″ top spud
With tail to fit Sloan/Zurn stop
Adjustable 114mm (4.5”) to 131mm (5.18”) inlet/valve outlet centers
Maximum 292mm(11 1/2″) from centerline of valve inlet to top of water closet, except -1 trap seal models which are maximum 11 3/4″
Factory Set to 4.8L (1.27 Gal.) – not field adjustable
Product Certifications:
IAPMO listed to CSA B125.3/ ASSE 1037
ADA compliant to meet Handicapped Accessibility Standard ICC/ANSI A117.1 of less than 5 lbs. operating force
Additional Delta Links
View the Manufacturer Warranty
Browse all Delta Products
Delta Commercial Collection
Specifications
| Height | 13.9 in. |
| Product Weight | 3.1 lbs. |
| Gallons Per Flush | 1.28 |
| Spud Size | 1.5 in. |
| Material | Brass |
| Insulation Type | Deck Mounted |
| Handle Style | Lever |
| Handle Material | Metal |
| Control Type | Manual |
| Configuration | Exposed |
| Spud Placement | Top |
| Approved for Commercial Use | Yes |
| ADA | Yes |
| Country Of Origin | Canada |
| Made in America | Yes |
| CA Drought Compliant | Yes |
| Handshower Included | Yes |
| Color | Chrome |
| Color Tone | Silver Tones |
