Features:
Designed to support up to 100 pounds of weight
Mounts to the side of the drawer
Provides easy access to the drawer with full extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Self Closing: Gently push on the door front to engage the integrated spring mechanism. Once activated, these slides will close the drawer for you in one smooth movement.
Soft Close: Whether large or small, heavy or light, soft closing action keeps drawers from slamming closed. It adapts to various closing speeds and features overload safety to protect the system from damage over time.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 20-1/2″
Slide Length: 20″
Extension Type: Full Extension
Slide Type: Ball Bearing
Weight Capacity: 100 lbs
Material: Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Mounting hardware not included
Product Variations:
8450FMB 12: 12 Inch Drawer Slide
8450FMB 14: 14 Inch Drawer Slide
8450FMB 16: 16 Inch Drawer Slide
8450FMB 18: 18 Inch Drawer Slide
8450FMB 20 (This Model): 20 Inch Drawer Slide
8450FMB 22: 22 Inch Drawer Slide
8450FMB 24: 24 Inch Drawer Slide
8450FMB 26: 26 Inch Drawer Slide
8450FMB 28: 28 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt 8450FM Collection
Specifications
| Approved for Commercial Use | Yes, No |
| Series | 8450FM |
| BHMA Certification | Grade 1 |
| Collection | 8450FM |
| Manufacturer Warranty | Limited Lifetime |
| Height | 1.79 in. |
| Width | 0.5 in. |
| Length | 20 in. |
| Quantity | 2 |
| Nominal Length | 20 in. |
| Width mm | 13 mm |
| Extension | 20 in. |
| Max Capacity (Pounds) | 100 lbs. |
| Height mm | 46 mm |
| Drainboard Length | 20.5 in. |
| Maximum Drawer Width | 24 in. |
| Minimum Cabinet Depth | 20 in. |
| Minimum Clearance | 0.5 in. |
| Material | Steel |
| Insulation Type | Side Mount |
| Mounting Type | Side Mount |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Self Closing | Yes |
| Soft Close | Yes |
| Adjustable | No |
| Extension Type | Full Extension |
| Detent | No |
| Disconnect Style | Lever |
| Push to Open | No |
| Slide Type | Ball Bearing |
| Color | Anochrome |
| Color Tone | Silver Tones |
