Features:
Designed to support up to 90 pounds of weight
Mounts to the side of the drawer
Provides maximum access to the drawer with overtravel slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Self Closing: Gently push on the door front to engage the integrated spring mechanism. Once activated, these slides will close the drawer for you in one smooth movement.
Soft Close: Whether large or small, heavy or light, soft closing action keeps drawers from slamming closed. It adapts to various closing speeds and features overload safety to protect the system from damage over time.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 24-1/2″
Slide Length: 24″
Extension: Type: Over Travel
Slide Type: Ball Bearing
Weight Capacity: 90 lbs
Material: Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Mounting hardware not included
Product Variations:
8455FMB 16: 16 Inch Drawer Slide
8455FMB 18: 18 Inch Drawer Slide
8455FMB 20: 20 Inch Drawer Slide
8455FMB 22: 22 Inch Drawer Slide
8455FMB 24 (This Model): 24 Inch Drawer Slide
8455FMB 28: 28 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt 8455FM Collection
Specifications
| Height | 1.79 in. |
| Width | 0.5 in. |
| Length | 24 in. |
| Nominal Length | 24 in. |
| Quantity | 2 |
| Max Capacity (Pounds) | 90 lbs. |
| Height mm | 46 mm |
| Width mm | 13 mm |
| Minimum Clearance | 0.5 in. |
| Drainboard Length | 24.5 in. |
| Minimum Cabinet Depth | 24 in. |
| Maximum Drawer Width | 24 in. |
| Material | Steel |
| Insulation Type | Side Mount |
| Mounting Type | Side Mount |
| Adjustable | No |
| Extension Type | Over Travel |
| Soft Close | Yes |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Self Closing | Yes |
| Push to Open | No |
| Detent | No |
| Disconnect Style | Lever |
| Slide Type | Ball Bearing |
| Collection | 8455FM |
| Approved for Commercial Use | Yes, No |
| Manufacturer Warranty | Limited Lifetime |
| Series | 8455FM |
| BHMA Certification | Grade 1 |
| Color | Anochrome |
| Color Tone | Silver Tones |
