PLEASE NOTE: When selecting Keying Options above, this item is treated as two separate items. By selecting “Keyed Alike” the handle and deadbolt will be keyed alike. Selecting “Keyed Differently” the handle and deadbolt will be keyed to two different keys. When ordering multiple combo packs on the same order, “Keyed Alike” means every handle and deadbolt will be keyed to the same key. “Keyed Differently” means every handle and deadbolt will be keyed to different keys. If you require different groups of combo packs to be “Keyed Alike”, separate orders will be required. Please contact customer service if you need help determining your needs.
Single Cylinder Function: Single cylinder deadbolts are keyed on the exterior with an associated thumb turn on the inside that can quickly and easily lock or unlock the latch mechanism. Single cylinder locks are most commonly used to secure entrances to a residence or place of business.
Knob Keyed Entry (Single Cylinder) Function: Single cylinder keyed entry door hardware is locked and unlocked from the exterior using a key and can be locked and unlocked from the interior using the locking mechanism. Perfect for securing entrances, side doors, and anywhere else that needs a bit more security.
Knob Features:
Knobset and deadbolt both exceed ANSI/BHMA security standards
All metal construction for long-lasting durability and a premium feel
Handing is reversible for either left or right door configurations
Deadbolt and dead latch are 6 way adjustable
Installs easily into most standard prepared doors
Lifetime mechanical and finish warranty
Deadbolt Features:
BHMA Grade 1
Designed for left or right handed doors
Includes round, square, and drive-in latch to fit all standard doors
Includes round corner deadbolt strike
Adjustable backset to fit all standard door preparations
Lifetime mechanical and finish warranty
Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys
Key Product Attribute:
SmartKey®:Â
This technology allows you to re-key your lock in seconds with 3 simple steps and features stainless steel racks, pins, and side locking bar for increased strength and security.
Knob Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Latch Faceplate: Round Corner, Square Corner, Drive-In
Cylinder: SmartKey 5 Pin
Deadbolt Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″, 1-1/2″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Cylinder: SmartKey 5 Pin
Additional Kwikset Links
View the Manufacturer Warranty
Browse all Kwikset Products
Kwikset Abbey Collection
Specifications
| Thermostat | Transitional |
| Material | Brass, Zinc |
| Handshower | Left, Reversible, Right |
| Handle Style | Knob |
| Handle Material | Metal |
| Concealed Screws | No |
| Cylinder | SmartKey 5 Pin |
| Cylinder Type | Single Cylinder |
| Function | Keyed Entry |
| Handle Design | Abbey |
| Keyway | KW1 |
| Latch Faceplate | Drive-In, Round Corner, Square Corner |
| Rosette Shape | Round |
| Knob Shape | Tulip |
| Panic Proof | No |
| Lock Style | Two Point |
| ADA | Yes |
| Collection | Abbey |
| Manufacturer Warranty | Limited Lifetime Finish, Limited Lifetime Mechanical |
| Certifications | ANSI, UL |
| Approved for Commercial Use | No |
| Series | Signature Series |
| Fire Rated | Yes |
| ANSI Certification | A156.2, A156.36 |
| BHMA Certification | Grade 1, Grade 3 |
| Product Weight | 4 lbs. |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Cross Bore | 1-1/2", 2-1/8" |
| Edge Bore | 1" |
| Trim Height | 2.625 in. |
| Trim Width | 2.625 in. |
| Handle Height | 2.031 in. |
| Handle Projection | 2.6875 in. |
| Handle Width | 2.031 in. |
| Cylinder Included | Yes |
| Color | Antique Brass, Polished Brass, Satin Chrome |
Reviews
There are no reviews yet.
