Size 2 Regular/Parallel Arm Grade 2 Door Closer from the GC800 Series
Pamex door closers set industry standards for quality, durability, and innovation. With the toughness and reliability that are a signature of Pamex hardware, Pamex is able to provide limited warranties on its door closers for 10 years.
Established in 1985, Pamex Inc. is a manufacturer of builder’s hardware. They provide residential and commercial door locks, bath accessories, door hardware and hospitality accessories to the residential and multi-family industry. Their goal is to offer quality products with excellent price point to all of our customers.
Features:
Constructed with precise aluminum die-cast body and steel arm
A heat-treated steel rack and pinion immersed in high-grade oil operate a nest of coils to give a smooth and precise action with minimum wear.
Stable hydraulic fluid for any climatic operation and constant lubrication
Adjustable closing and latching speed
Universal application and non-handed installation
UL Listed
ANSI Grade 2
Package includes parallel bracket and wooden and machine screws to fit wood and metal doors
Sex bolts and thru bolts not included
Additional Pamex Links
Browse all Pamex Products
Pamex GC800 Collection
Specifications
| Height | 1.75 in. |
| Projection | 2.875 in. |
| Max Door Weight | 110 lbs. |
| Max Door Width | 32 in. |
| Closer Body Length | 7.375 in. |
| Closer Size | 2 |
| Horizontal Mounting Holes | 6.625 in. |
| Max Door Opening | 180 Degrees |
| Vertical Mounting Holes | 6.625 in. |
| Material | Aluminum |
| Arm Type | Standard |
| Handshower | Left, Reversible, Right |
| Barrier Free | No |
| Adjustable Backcheck | No |
| Adjustable Spring | No |
| Delay Action | No |
| Hold Open | No |
| Mounting | Parallel, Regular |
| Operation Mode | Hydraulic |
| Shell Material | Plastic |
| Approved for Commercial Use | Yes |
| Collection | 800 |
| Manufacturer Warranty | 10 Year |
| ADA | No |
| Series | 800 |
| Certifications | ANSI, UL10C, UL |
| ANSI Certification | A156.4 |
| Fire Rated | Yes |
| Usage Level | Standard Duty |
| BHMA Certification | Grade 1 |
| Cushion Stop | No |
| Adjustable Closing Speed | Yes |
| Adjustable Latching Speed | Yes |
| Color | Aluminum |
| Color Tone | Neutrals |
