Zoeller 63-0001 Features:
Float-operated, submersible, 2-pole mechanical switch integrating advanced switch technology
Corrosion-resistant, powder coated epoxy finish
All cast iron construction
Viton outer switch boot
No sheet metal parts to rust or corrode
Stainless steel screws, switch arm, guard and handle
No screens to clog
Watertight, neoprene square ring between motor and pump housing
Solid, buoyant, polypropylene float
Oil-filled, hermetically-sealed, automatic reset thermal overload protected motor
Upper and lower sleeve bearings running in bath of oil
Entire unit pressure-tested after assembly
Carbon and ceramic shaft seal
Passes 1/2” spherical solids
1-1/2” NPT discharge
On point: 7-1/4”
Zoeller 63-0001 Specifications:
Height: 10-1/16″
Width: 10-1/16″
Motor: 3/10 HP
Voltage: 115
RPM: 1550
Discharge Size: 1-1/2″ NPT
Max Flow Rate: 43 gallons per minute
Max Operating Temperature: 130
Additional Zoeller Links
View the Manufacturer Warranty
Zoeller Premium Series Collection
Specifications
| Height | 10.0625 in. |
| Product Weight | 28.5 lbs. |
| Width | 10.0625 in. |
| Length | 7.875 in. |
| Water Connection | 1-1/2" |
| Cord Length | 10 in. |
| Discharge Diameter | 1.5 in. |
| Maximum Head Height | 19 in. |
| Maximum Flow Rate | 43 GPM |
| Material | Cast Iron |
| Impeller Material | Cast Iron |
| Material Shaft | Steel |
| Submersible | Yes |
| Voltage | 115 |
| Amperage | 9.7 |
| Horsepower | 0.3 |
| Electrical Phases | 1 |
| Maximum Fluid Temperature | 130 °F |
| Motor RPM | 1550 |
| Operating Temperature (Max) | 130 °F |
| Collection | Model 63 |
| Country Of Origin | USA |
| Manufacturer Warranty | 5 Years |
| Approved for Commercial Use | Yes |
| Made in America | Yes |
