Features:
Constructed from steel to ensure long lasting durability
Intended for easy installation on steel, vinyl, and wood gates
Closes large and small gates up to 125 pounds
Fits maximum gate width of 52″ and has a opening force 3 to 7 pounds
Hydraulic and nitrogen gas controlled closing speed prevents slamming
Reversible handing installs on left or right handed gates and can be mounted top, middle, or bottom gates
Includes all necessary mounting hardware
May be installed on chain-link gate with LINX Kit
Covered under a 1 Year Limited Warranty
Product Technologies:
Reversible Handing: The handing on this gate closer is reversible to accommodate both left-hand and right-hand gates. We remove the guesswork and make it easy to choose the gate closer you want.
Specifications:
Height: 3″
Length: 33″
Width: 3″
Handing: Reversible Left or Right
Mount Position: Offset
Max Weight Capacity: 125 lbs.
Opening Angle: 100°
Operating Temperature (Min): 15°F
Operating Temperature (Max): 122°F
Closing / Latch Method: Hydraulic / Nitrogen Gas
Hinge Arrangements: In-line or Offset
Material: Steel
Additional Lockey Links
View the Manufacturer Warranty
Browse all Lockey Products
Lockey TB Collection
Specifications
| Height | 3 in. |
| Width | 3 in. |
| Length | 33 in. |
| Product Weight | 6 lbs. |
| Quantity | 1 |
| Maximum Width | 52 in. |
| Opening Angle | 100 |
| Max Capacity (Pounds) | 125 lbs. |
| Thermostat | Transitional |
| Material | Steel |
| Mounting Type | Surface Mount |
| Handshower | Left, Reversible, Right |
| Panic Proof | Yes |
| Installation Hardware Included | Yes |
| Approved for Commercial Use | Yes, No |
| Collection | Turtleback |
| Manufacturer Warranty | 1 Year Limited |
| ADA | No |
| Series | TB |
| Application | Gate Hardware |
| Fire Rated | No |
| Power Source | Hydraulic |
| Operating Temperature (Max) | 122 °F |
| Operating Temperature (Min) | 15 °F |
| Color | Black |
| Color Tone | Blacks |
