Features:
Constructed from steel to ensure long lasting durability
Intended for easy installation on heavy duty steel gates
Closes large gates up to 250 lbs. with maximum gate width of 52″
Fits maximum gate width of 52″
Reversible handing installs on left or right handed gates and can be mounted top, middle, or bottom gates
Includes all necessary mounting hardware
May be installed on chain-link gate with LINX Kit
Covered under a 10 Year Limited Warranty
Product Technologies:
Reversible Handing: The handing on this gate closer is reversible to accommodate both left-hand and right-hand gates. We remove the guesswork and make it easy to choose the gate closer you want.
Self Closing: Gently push on the gate front to engage the integrated spring mechanism. Once activated, these slides will close the gate for you in one smooth movement.
Specifications:
Height: 6″
Length: 16″
Width: 3″
Handing: Reversible Left or Right
Mount Position: Offset
Max Weight Capacity: 250 lbs.
Opening Angle: 90°
Operating Temperature (Min): -40°F
Constant Closing Pressure: 135 lbs.
Material: Steel
Additional Lockey Links
View the Manufacturer Warranty
Browse all Lockey Products
Lockey TB Collection
Specifications
| Height | 6 in. |
| Product Weight | 25 lbs. |
| Length | 16 in. |
| Quantity | 1 |
| Maximum Width | 48 in. |
| Max Capacity (Pounds) | 250 lbs. |
| Opening Angle | 90 |
| Thermostat | Transitional |
| Material | Steel |
| Concealed Screws | Yes |
| Mounting Type | Surface Mount |
| Handshower | Left, Reversible, Right |
| Panic Proof | Yes |
| Self Closing | Yes |
| Power Source | Hydraulic |
| Operating Temperature (Min) | -40 °F |
| Adjustable Closing Speed | Yes |
| Adjustable Latching Speed | Yes |
| Collection | Turtleback |
| Manufacturer Warranty | 10 Year Limited |
| Approved for Commercial Use | No, Yes |
| Series | TB |
| ADA | No |
| Fire Rated | No |
| Application | Gate Hardware |
| Installation Hardware Included | Yes |
| Color | Zinc |
