Features:
Constructed from stainless steel to ensure long lasting durability
Intended for easy installation on steel, vinyl, and wood gates
Closes large and small gates up to 175 pounds
Fits maximum gate width of 64″ and has a opening force 6 to 12 pounds
Hydraulic and nitrogen gas controlled closing speed prevents slamming
Reversible handing installs on left or right handed gates and can be mounted top, middle, or bottom gates
Includes all necessary mounting hardware
May be installed on chain-link gate with LINX Kit
Covered under a 1 Year Limited Warranty
Product Technologies:
Reversible Handing: The handing on this gate closer is reversible to accommodate both left-hand and right-hand gates. We remove the guesswork and make it easy to choose the gate closer you want.
Specifications:
Height: 3″
Length: 33″
Width: 3″
Handing: Reversible Left or Right
Mount Position: Offset
Max Weight Capacity: 175 lbs.
Opening Angle: 100°
Operating Temperature (Min): 15°F
Operating Temperature (Max): 122°F
Constant Closing Pressure: 45 lbs.
Closing / Latch Method: Hydraulic / Nitrogen Gas
Hinge Arrangements: In-line or Offset
Material: Stainless Steel
Additional Lockey Links
View the Manufacturer Warranty
Browse all Lockey Products
Lockey TB Collection
Specifications
| Height | 3 in. |
| Width | 3 in. |
| Length | 33 in. |
| Product Weight | 6 lbs. |
| Maximum Width | 64 in. |
| Quantity | 1 |
| Max Capacity (Pounds) | 175 lbs. |
| Opening Angle | 100 |
| Material | Stainless Steel |
| Thermostat | Transitional |
| Mounting Type | Surface Mount |
| Handshower | Left, Reversible, Right |
| Panic Proof | Yes |
| Power Source | Hydraulic |
| Operating Temperature (Max) | 122 °F |
| Operating Temperature (Min) | 15 °F |
| Collection | Turtleback |
| Approved for Commercial Use | Yes, No |
| ADA | No |
| Manufacturer Warranty | 1 Year Limited |
| Fire Rated | No |
| Series | TB |
| Application | Gate Hardware |
| Installation Hardware Included | Yes |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
